TEY130 - 30Amp Circuit Breaker

TEY130 - 30Amp Circuit Breaker

Elevate the safety and functionality of your electrical system with the TEY130 - TEY 1 Pole 30 Amp Circuit Breaker. Designed for demanding applications, this compact and robust breaker is perfect for use in grounded 480Y/277 Vac systems, providing essential protection and reliable performance.

Key Features and Benefits:

• Compact Design: The TEY130 features a narrow, one-inch width per pole, making it ideal for space-constrained environments.
• Bolt-On Installation: The bolt-on mounting base ensures a secure and reliable installation, making it suitable for varied applications as a lug-lug breaker.
• Quick-Make/Quick-Break Mechanism: This feature allows for rapid interruption of electrical flows, enhancing safety by reducing the risk of electrical fires or damage.
• Trip Indication: The clear and easy-to-spot trip indication allows for immediate identification of tripped circuits, simplifying troubleshooting and maintenance.
• Versatility: Available in 1, 2, and 3 pole versions, with optional auxiliary contacts and shunt trip accessories, catering to diverse electrical system requirements.

Technical Specifications:

• Amperage: 30 A
• System Voltage Options: 120 Vac, 120/240 Vac, 240 Vac, and 277 Vac
• Interrupting Ratings: Up to 65 KAIC at 120 Vac
• Trip Style: Non-Interchangeable
• Trip Function: LI, with fixed long-time and instantaneous settings
• Certifications: UL Listed (File #E11592), CSA Certified (File# LR57114)

Material Compliance and Certifications:

• The TEY130 circuit breaker complies with key industry standards and certifications, ensuring top quality and safety. It is UL listed and CSA certified, meeting rigorous North American standards for safety and performance.

Suitability:

• Ideal for both commercial and industrial applications, this circuit breaker supports reverse feed use and is suitable for use in lighting panels. Its high interrupting rating and compact, bolt-on design make it a versatile choice for panelboards and switchboards in a variety of settings.
