TEY115 - 15Amp Circuit Breaker

TEY115 - 15Amp Circuit Breaker

Optimize your electrical setup with the TEY115 TEY 1 POLE 15AMP Circuit Breaker, your ultimate solution for dependable power management. Designed for use on grounded 480Y/277 Vac systems, this bolt-on circuit breaker delivers a combination of innovation and efficiency. Compact and robust, it occupies only one-inch per pole, making it an excellent choice for installations where space is at a premium.

Key Features and Benefits:

• Quick-make / Quick-break Mechanism: Ensures rapid and reliable operation, reducing the time under fault conditions, which significantly enhances safety.
• Trip Indication: Easily identifiable trip status, ensuring maintenance and troubleshooting are straightforward and minimizing downtime.
• Bolt-on Mounting Base: Facilitates secure attachment and enhances the reliability of electrical connections, suitable for various applications.
• Versatility: Available in 1, 2, and 3 pole versions with options for auxiliary contacts and shunt trip accessories, making it adaptable to a range of operational needs.

Technical Specifications:

• Amperage: 15A
• System Voltage: Compatible with systems up to 277 Vac.
• Interrupting Ratings: Provides high interrupting capacity up to 65 KAIC at 120 Vac, ensuring effective fault clearance and added safety.
• Trip Function: Fixed LI to offer consistent performance.
• Wire Range: Accommodates 14-8 kcmil (Cu/Al), supporting a wide range of wiring needs.

Material Compliance and Certifications:

• UL Listed (File #E11592): Ensures compliance with stringent safety standards.
• CSA Certified (File# LR57114): Further guarantees reliability and safety for use in various environments.

Suitability:

• Reverse Feed: Yes, allows for flexibility in installation and application.
• Special Markings: Includes HACR and HID, making it suitable for heating, air-conditioning, and high-intensity discharge lighting applications.

Crafted to meet the highest industry standards, the TEY115 offers an exceptional blend of functionality and durability. Whether you are upgrading your panel or setting up a new installation, this circuit breaker provides the performance and reliability needed to handle modern electrical loads efficiently.
