GENERAL ELECTRIC
TED136150WL **Older Style** - 150Amp Circuit Breaker
TED136150WL **Older Style** - 150Amp Circuit Breaker
Couldn't load pickup availability
TED136150WL **Older Style** - 150Amp Circuit Breaker
Finding the right replacement for your circuit breaker involves more than matching the amperage printed on its label. Pole configuration, interrupting capacity, trip mechanism, terminal connections, and physical dimensions all matter when maintaining existing electrical equipment. The ABB TED136150WL Black Face Circuit Breaker is a 150-amp, 3-pole molded-case industrial circuit breaker intended for compatible industrial and commercial electrical applications. Equipped with a non-interchangeable thermal-magnetic trip unit, it provides overload and short-circuit protection for equipment requiring the established electrical characteristics of the ABB TED series.
Key Features and Benefits
- 150-Amp, 3-Pole Configuration:
- Multiple Interrupting Capacity Ratings:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Line and Load-Side Lugs Included:
- Black-Face TED Series Construction:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED136150WL
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 150 Amps
-
Number of Poles: 3
-
Interrupting Capacity at 600VAC: 14 kAIC
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Line and Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 4.13 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 4.13 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 6.50 lbs
-
UPC: 00783164132977
Material Compliance and Certifications
The available product specifications do not include specific material composition, UL or CSA listing information, RoHS compliance, or other regulatory certifications.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Distribution:
- Black-Face TED Breaker Replacement:
- Applications Requiring Line and Load-Side Lugs:
