GENERAL ELECTRIC
TED136150 **Older Style** - 150Amp Circuit Breaker
TED136150 **Older Style** - 150Amp Circuit Breaker
Couldn't load pickup availability
TED136150 **Older Style** - 150Amp Circuit Breaker
Finding the right replacement for your circuit breaker means looking beyond the amperage rating on its label. Pole configuration, interrupting capacity, trip mechanism, terminal connections, and physical dimensions all matter when maintaining existing electrical equipment. The ABB TED136150 Black Face Circuit Breaker is a 150-amp, 3-pole molded-case industrial circuit breaker intended for compatible industrial and commercial electrical applications. With a non-interchangeable thermal-magnetic trip unit, it provides overload and short-circuit protection for electrical systems that require the established characteristics of the ABB TED series.
Key Features and Benefits
- 150-Amp, 3-Pole Configuration:
- Multiple Interrupting Capacity Ratings:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Load-Side Lugs Included:
- Black-Face TED Series Construction:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED136150
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 150 Amps
-
Number of Poles: 3
-
Interrupting Capacity at 600VAC: 14 kAIC
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 4.13 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 4.13 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 6.50 lbs
-
UPC: 00783164132960
Material Compliance and Certifications
Specific material composition, UL or CSA listing information, RoHS compliance, and other regulatory certifications have not been provided in the available product specifications.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Distribution:
- Black-Face TED Breaker Replacement:
