TED136090 **Older Style** - 90Amp Circuit Breaker
TED136090 **Older Style** - 90Amp Circuit Breaker
Couldn't load pickup availability
TED136090 **Older Style** - 90Amp Circuit Breaker
Finding the right replacement for your circuit breaker means more than matching the amperage on the label. Pole configuration, interrupting capacity, trip mechanism, terminal connections, and physical dimensions all matter when maintaining existing electrical equipment. The ABB TED136090 Black Face Circuit Breaker is a 90-amp, 3-pole molded-case industrial circuit breaker designed for compatible industrial and commercial electrical applications. With a non-interchangeable thermal-magnetic trip unit, it provides overload and short-circuit protection for equipment that requires the established electrical characteristics of the ABB TED series.
Key Features and Benefits
- 90-Amp, 3-Pole Configuration:
- Multiple Interrupting Capacity Ratings:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Load-Side Lugs Included:
- Black-Face TED Series Construction:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED136090
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 90 Amps
-
Number of Poles: 3
-
Interrupting Capacity at 600VAC: 14 kAIC
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 4.13 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 4.13 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 6.50 lbs
-
UPC: 00783164063530
