TED136060WL **Older Style** - 60Amp Circuit Breaker

TED136060WL **Older Style** - 60Amp Circuit Breaker

The TED136060WL circuit breaker, a part of the renowned E150 product line, is an advanced thermal magnetic circuit breaker designed to deliver reliable and efficient performance in various electrical systems. Ideal for commercial and industrial applications, this circuit breaker offers exceptional protection and operational efficiency, ensuring safety and longevity of electrical installations.

Key Features and Benefits:

• Versatile Voltage Compatibility: Supports a wide range of system voltages, including 120 Vac, 120/240 Vac, 125 Vdc, 240 Vac, 250 Vdc, 277 Vac, 480 Vac, 500 Vdc, and 600 Vac, making it suitable for diverse applications.
• High Interrupting Capacity: With interrupting ratings up to 18 KAIC, the TED136060WL provides robust protection against short circuits and electrical faults.
• Thermal Magnetic Protection: Combines thermal and magnetic tripping mechanisms to offer precise and reliable protection for electrical circuits, preventing overloads and short circuits.
• Fixed Trip Function: Features a fixed long time and instantaneous trip function (LI), ensuring consistent and dependable performance.
• Cu/Al Line and Load Lugs: The WL suffix indicates that the circuit breaker comes equipped with copper/aluminum line and load lugs, enhancing connectivity and reducing installation time.

Technical Specifications:

• Amperage: 60 A
• Poles: 3
• Frame Type: E150
• Interrupting Ratings: 120 Vac: 18 KAIC, 120/240 Vac: 18 KAIC, 125 Vdc: 10 KAIC, 240 Vac: 18 KAIC, 250 Vdc: 10 KAIC, 277 Vac: 18 KAIC, 480 Vac: 18 KAIC, 500 Vdc: 10 KAIC, 600 Vac: 14 KAIC
• Trip Function: LI (Long Time and Instantaneous)
• Suitable for Reverse Feed: Yes
• Lugs: TC041, TCAL12, TCAL14
• UL File #: E11592
• CSA File #: LR57114

Material Compliance and Certifications:

• Compliance: The TED136060WL circuit breaker complies with UL and CSA standards, ensuring it meets stringent safety and performance criteria. The use of high-quality materials and rigorous testing procedures guarantees durability and reliability in demanding environments.

Suitability:

• This circuit breaker is perfect for protecting electrical circuits in commercial buildings, industrial facilities, and other high-demand environments. Its ability to handle various voltages and its high interrupting capacity make it a versatile and dependable choice for electrical system protection.

The TED136060WL circuit breaker is more than just a component; it's a critical element in maintaining the safety and reliability of your electrical systems. Explore more about this essential circuit breaker today to ensure your systems remain secure and compliant.
