TED136020WL **Older Style** - 20Amp Circuit Breaker

TED136020WL **Older Style** - 20Amp Circuit Breaker

The TED136020WL circuit breaker from ABB's E150 product line is designed to provide exceptional protection and reliability for high-voltage electrical systems. Engineered with precision, this 3-pole, 600VAC, 20A breaker is ideal for a variety of industrial and commercial applications, ensuring robust performance and enhanced safety.

Key Features and Benefits:

• Versatile Protection: The TED136020WL offers both thermal magnetic and magnetic trip functions, ensuring comprehensive protection against overloads and short circuits.
• High Interrupting Capacity: With an interrupting rating of up to 18 KAIC for most voltage levels, this breaker ensures reliable performance even under extreme fault conditions.
• Durable Construction: Built with high-quality materials, the breaker features Cu/Al line and load lugs, providing secure and efficient connections.

Technical Specifications:

• Poles: 3
• System Voltage: Up to 600VAC / 500VDC
• Amperage: 20A
• Interrupting Ratings: 120VAC: 18 KAIC; 240VAC: 18 KAIC; 277VAC: 18 KAIC; 480VAC: 18 KAIC; 600VAC: 14 KAIC; 125VDC: 10 KAIC; 250VDC: 10 KAIC; 500VDC: 10 KAIC
• Trip Function: LI (Long Time and Instantaneous)
• Continuous Current Rating: Standard
• Lugs: TC041, TCAL14

Material Compliance and Certifications:

• UL Listed: File #E11592
• CSA Certified: File #LR57114
• HACR Rated: Suitable for use with HVAC applications
• GSA Compliance: No

Suitability:

• The TED136020WL is ideal for applications in commercial buildings, industrial plants, and other facilities that require reliable high-voltage circuit protection. Its robust design and versatile functionality make it suitable for a variety of environments, ensuring both safety and efficiency.
