TED134110 - 110Amp Circuit Breaker
TED134110 - 110Amp Circuit Breaker
Couldn't load pickup availability
TED134110 - 110Amp Circuit Breaker
When you replace a circuit breaker in an existing electrical system, find the right match by looking beyond amperage alone. Pole configuration, interrupting capacity, trip mechanism, terminal connections, and physical dimensions all matter. The ABB TED134110 Black Face Circuit Breaker is a 110-amp, 3-pole molded-case industrial circuit breaker designed for compatible industrial and commercial electrical applications. With a non-interchangeable thermal-magnetic trip unit, it provides overload and short-circuit protection for installations that require the established electrical characteristics of the ABB TED series. For electricians, facility managers, and maintenance professionals servicing legacy equipment, the TED134110 offers a practical replacement option when maintaining the original form, fit, and function is essential.
Key Features and Benefits
- 110-Amp, 3-Pole Configuration:
- 18 kAIC Interrupting Rating:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Load-Side Lugs Included:
- Black-Face TED Series Construction:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED134110
-
UPC: 00783164236811
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 110 Amps
-
Number of Poles: 3
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 4.13 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 4.13 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 6.50 lbs
Material Compliance and Certifications
The ABB TED134110 Black Face Circuit Breaker features molded-case construction and a non-interchangeable thermal-magnetic trip unit. Its specified interrupting capacities are 18 kAIC at 480VAC and 18 kAIC at 240VAC. These ratings describe the breaker's ability to interrupt fault current at the stated voltages and should not be interpreted as separate nominal operating voltage ratings.
The available product specifications do not include specific material composition, UL or CSA listing information, RoHS compliance, or other regulatory certifications. If an installation requires documentation of particular electrical or material standards, consult the applicable product markings and ABB manufacturer documentation. The stated electrical ratings alone do not establish certification or compliance with every applicable industry requirement.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Distribution:
- Black-Face TED Breaker Replacement:
- Planned Electrical Maintenance:
