TED134045WL - 45Amp Circuit Breaker

TED134045WL - 45Amp Circuit Breaker

When you need a compatible replacement for a Type TED molded case circuit breaker, the TED134045WL delivers the ratings and configuration your existing electrical system was designed to use. This 3-pole, 45-amp circuit breaker features a non-interchangeable thermal magnetic trip unit that helps protect circuits from overloads and short circuits, making it a dependable choice for maintaining commercial and industrial power distribution systems.

Designed with an 18k A.I.C. interrupting rating at both 240VAC and 480VAC, the TED134045WL is built for applications where dependable circuit protection matters every day. It also includes line-side and load-side lugs, helping simplify installation in compatible equipment. Whether you're replacing a worn breaker during routine maintenance or servicing an existing electrical distribution system, this breaker provides the form, fit, and functional compatibility needed to keep your equipment operating as intended. Built to last, it's a practical solution for maintaining legacy electrical systems without changing the original design.

Key Features and Benefits

• 45-amp current rating: For commercial and industrial electrical applications.
• Three-pole design: For three-phase power distribution systems.
• Type TED molded case circuit breaker: For compatible installations.
• Non-interchangeable thermal magnetic trip unit: Helps protect against overloads and short circuits.
• Interrupting capacity: Rated 18k A.I.C. at 240VAC and 480VAC.
• Line-side and load-side lugs included: For added installation convenience.
• Form, fit, and functional replacement: Designed for compatible Type TED applications.
• Built to last: For dependable long-term service.


Technical Specifications

• Part Number: TED134045WL

• Product Type: Molded Case Industrial Circuit Breaker

• Type: TED

• Poles: 3

• Amperage: 45 Amps

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Interrupting Rating: 18k A.I.C. @ 240VAC; 18k A.I.C. @ 480VAC

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.
• Included: Line-Side and Load-Side Lugs


Material Compliance and Certifications

• Commercial and Industrial Use: The TED134045WL is manufactured for use in commercial and industrial electrical distribution systems and is designed to meet the published electrical ratings associated with the Type TED product family.
• Installation Requirements: Always verify compatibility with your equipment, applicable electrical ratings, and local code requirements before installation. Installation should be completed by qualified electrical personnel.


Where It Works Best

• The TED134045WL is commonly used in commercial facilities, manufacturing plants, industrial control equipment, distribution panels, and other three-phase electrical systems that require a 45-amp, 3-pole Type TED molded case circuit breaker. It's an excellent choice when maintaining existing equipment, allowing you to preserve the original form, fit, and function of your electrical system while restoring reliable circuit protection.
