TED124100 **Older Style** - 100Amp Circuit Breaker
TED124100 **Older Style** - 100Amp Circuit Breaker
Couldn't load pickup availability
TED124100 **Older Style** - 100Amp Circuit Breaker
Finding the right circuit breaker for your existing electrical system means looking beyond amperage alone. Pole configuration, interrupting capacity, trip mechanism, terminal connections, and physical dimensions all affect compatibility. The ABB TED124100 Black Face Circuit Breaker is a 100-amp, 2-pole molded-case industrial circuit breaker designed for electrical installations that require the TED series' established characteristics.
Key Features and Benefits
- 100-Amp, 2-Pole Configuration:
- 18 kAIC Interrupting Rating:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Load-Side Lugs Included:
- Black-Face TED Series Design:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED124100
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 100 Amps
-
Number of Poles: 2
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 2.75 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 2.75 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 4.50 lbs
Material Compliance and Certifications
The ABB TED124100 Black Face Circuit Breaker features molded-case construction and a non-interchangeable thermal-magnetic trip unit. Its specified interrupting capacities are 18 kAIC at 480VAC and 18 kAIC at 240VAC. These ratings describe the breaker's ability to interrupt fault current at the stated voltages and should not be interpreted as separate nominal operating voltage ratings.
The available product specifications do not include specific material composition, UL or CSA listing information, RoHS compliance, or other regulatory certifications. If your installation requires particular certifications or material compliance documentation, verify the applicable product markings and ABB manufacturer documentation before installation. Electrical ratings alone do not establish compliance with every applicable industry standard.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Systems:
- Black-Face TED Breaker Replacement:
- Scheduled Electrical Repairs:
