TED124070WL **Older Style** - 70Amp Circuit Breaker
TED124070WL **Older Style** - 70Amp Circuit Breaker
Couldn't load pickup availability
TED124070WL **Older Style** - 70Amp Circuit Breaker
When it's time to replace a circuit breaker in your existing electrical system, getting the specifications right is essential. The ABB TED124070WL Black Face Circuit Breaker is a 70-amp, 2-pole molded-case industrial circuit breaker designed for applications that require the TED series' established electrical ratings and physical configuration. Equipped with a non-interchangeable thermal-magnetic trip unit, this breaker provides overload and short-circuit protection for compatible industrial and commercial electrical equipment. It's a practical replacement option when maintaining the original form, fit, and function is the priority.
Key Features and Benefits
- 70-Amp, 2-Pole Configuration:
- 18 kAIC Interrupting Rating:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Line and Load-Side Lugs Included:
- Black-Face TED Series Design:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED124070WL
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 70 Amps
-
Number of Poles: 2
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Line and Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 2.75 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 2.75 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 4.50 lbs
Material Compliance and Certifications
The ABB TED124070WL Black Face Circuit Breaker features molded-case construction with a non-interchangeable thermal-magnetic trip unit. Its specified interrupting capacities are 18 kAIC at 480VAC and 18 kAIC at 240VAC. These values describe the breaker's fault-current interruption capability at the stated voltages and should not be interpreted as a separate nominal operating voltage rating.
The available product specifications do not include specific material composition, UL or CSA listing information, RoHS compliance, or other regulatory certifications. If your installation requires particular certifications or material compliance documentation, verify the applicable product markings and ABB manufacturer documentation before installation.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Systems:
- Black-Face TED Breaker Replacement:
- Scheduled Electrical Repairs:
