TED124060 **Older Style** - 60Amp Circuit Breaker
TED124060 **Older Style** - 60Amp Circuit Breaker
Couldn't load pickup availability
TED124060 **Older Style** - 60Amp Circuit Breaker
Finding the right replacement circuit breaker for your existing electrical system means getting the details right. The ABB TED124060 Black Face Circuit Breaker is a 60-amp, 2-pole molded-case industrial circuit breaker designed for applications that require the TED series' established electrical characteristics and physical configuration. Equipped with a non-interchangeable thermal-magnetic trip unit, this breaker provides overload and short-circuit protection for compatible industrial and commercial electrical equipment. When maintaining the original form, fit, and function of an installation matters, the TED124060 offers a replacement option with clearly defined specifications.
Key Features and Benefits
- 60-Amp, 2-Pole Configuration:
- 18 kAIC Interrupting Rating:
- Thermal-Magnetic Trip Protection:
- Non-Interchangeable Trip Unit:
- Load-Side Lugs Included:
- Black-Face TED Series Design:
- Form, Fit, and Function Replacement:
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED124060
-
Product Type: Molded-Case Industrial Circuit Breaker
-
Series / Type: TED
-
Face Color: Black
-
Amperage: 60 Amps
-
Number of Poles: 2
-
Interrupting Capacity at 480VAC: 18 kAIC
-
Interrupting Capacity at 240VAC: 18 kAIC
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Lug Configuration: Load-Side Lugs Included
-
Height: 6.31 inches
-
Width: 2.75 inches
-
Depth: 3.38 inches
-
Dimensions (W × H × D): 2.75 × 6.31 × 3.38 inches
-
Approximate Shipping Weight: 4.50 lbs
Material Compliance and Certifications
The ABB TED124060 Black Face Circuit Breaker features molded-case construction and a non-interchangeable thermal-magnetic trip unit. Its specified interrupting capacities are 18 kAIC at 480VAC and 18 kAIC at 240VAC. These values describe the breaker's fault-current interruption capability at the stated voltages and should not be interpreted as a separate nominal operating voltage rating.
If your installation requires documented certifications or compliance with particular material standards, verify the applicable product markings and manufacturer documentation before installation.
Where It Works Best
- Legacy Electrical System Maintenance:
- Industrial Electrical Equipment:
- Commercial Electrical Systems:
- Black-Face TED Breaker Replacement:
- Scheduled Electrical Repairs:
