TED124030 **Older Style** - 30Amp Circuit Breaker

TED124030 **Older Style** - 30Amp Circuit Breaker

The TED124030 is a robust and reliable 2-pole thermal magnetic circuit breaker designed for high performance in both residential and industrial applications. This circuit breaker operates at 480VAC and 250VDC with a current rating of 30 Amperes, ensuring optimal protection for your electrical systems. As part of the E150 product line, it boasts exceptional durability and efficiency, making it a critical component for safeguarding electrical circuits.

Key Features and Benefits:

• Dual Voltage Compatibility: Supports 480VAC and 250VDC, making it versatile for various electrical systems.
• Thermal Magnetic Operation: Combines both thermal and magnetic trip functionalities for precise overload and short-circuit protection.
• Compact and Durable Design: The compact molded-case design ensures durability and longevity, even in demanding environments.
• Reverse Feed Capability: Suitable for reverse feed applications, offering flexibility in installation.
• Wide Temperature Rating: 60/75°C rating through 100 amperes, ensuring reliable performance under various temperature conditions.

Technical Specifications:

• Poles: 2
• Voltage Rating: 480VAC / 250VDC
• Current Rating: 30A
• Frame Type: E150
• Trip Function: LI (Long-time and Instantaneous)
• Temperature Rating: 60/75°C through 100A, 75°C above 100A

Material Compliance and Certifications:

• Compliance: The TED124030 circuit breaker complies with all relevant industry standards, ensuring it meets rigorous safety and performance criteria. It features Cu/Al line and load lugs, supporting both copper and aluminum wiring for enhanced flexibility. It is designed to meet and exceed the requirements for thermal magnetic circuit breakers, guaranteeing reliable protection and peace of mind.

Suitability:

• Ideal for residential, commercial, and industrial applications, the TED124030 is engineered to protect electrical systems from overloads and short circuits. It is perfect for use in circuit protection for lighting, HVAC systems, and various other electrical equipment. Its robust construction and advanced thermal magnetic technology make it a trusted choice for electricians and contractors seeking reliable circuit protection solutions.
