TED124020WL - 20Amp Circuit Breaker
TED124020WL - 20Amp Circuit Breaker
Couldn't load pickup availability
TED124020WL - 20Amp Circuit Breaker
Finding the right replacement circuit breaker can be tricky, especially with an older electrical system. Two breakers might look nearly identical, yet have different trip characteristics, terminal connections, or interrupting ratings. Those differences matter.
The ABB TED124020WL is a 20-amp, 2-pole thermal magnetic molded-case circuit breaker from ABB's E150 family. It's designed for electrical equipment that requires this specific TED-series configuration, with a non-interchangeable trip mechanism, fixed long-time and instantaneous protection, and copper/aluminum line and load lugs included.
Key Features and Benefits
- 20-Amp Rating: Designed for circuits requiring a 20A breaker, subject to the equipment's electrical specifications and applicable installation requirements.
- Two-Pole Design: Provides the two-pole configuration required by compatible electrical distribution equipment.
- E150 Frame: Part of ABB's established E150 molded-case circuit breaker family.
- Thermal Magnetic Operation: Uses thermal and magnetic trip functions to respond to qualifying overload and short-circuit conditions.
- Fixed LI Trip Functions: Features fixed long-time and instantaneous protection characteristics.
- Non-Interchangeable Trip: The trip mechanism is part of the breaker configuration, not a separately interchangeable trip unit.
- Cu/Al Lugs Included: The WL suffix confirms that the breaker includes copper/aluminum line and load lugs.
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED124020WL
-
UPC: 783164067996
-
Product Type: Thermal Magnetic Molded-Case Circuit Breaker
-
Series: TED
-
Frame Type: E150
-
Rated Current: 20 Amps
-
Number of Poles: 2
-
Manufacturer Voltage Description: 480VAC / 250VDC
-
Trip Style: Non-Interchangeable
-
Trip Function: LI – Long-Time and Instantaneous
-
Long-Time Setting: Fixed
-
Instantaneous Setting: Fixed
-
Continuous Current Rating: Standard
-
Suitable for Reverse Feed: Yes
-
Line and Load Lugs: Included, Cu/Al
-
ABB Lug References: TC041, TCAL14
-
Special Marking: HACR
-
Current Metering: No
-
Protective Relays: No
-
GO Schedule: EB
-
GSA Compliance: No
-
UL File Number: E11592
-
CSA File Number: LR57114
-
Environmental Product Declaration: No Declaration Needed
Material Compliance and Certifications
When you maintain electrical equipment, documented product classifications can be as important as the physical fit.
ABB provides the following information for the TED124020WL.
- UL File Number: E11592
- CSA File Number: LR57114
Where It Works Best
The ABB TED124020WL is intended for electrical systems that require its particular combination of frame, amperage, poles, trip characteristics, and terminals.
Here are some situations where that configuration may be relevant.
- Existing Commercial Electrical Systems
- Industrial Maintenance and Repairs
- Legacy Electrical Equipment
- Matching Breaker Replacements
- HVAC-Related Electrical Equipment
- Reverse-Fed Electrical Arrangements
- Facility Maintenance Programs
- Electrical Restoration Projects
