TED124015WL - 15Amp Circuit Breaker
TED124015WL - 15Amp Circuit Breaker
Couldn't load pickup availability
TED124015WL - 15Amp Circuit Breaker
When your existing electrical system calls for a specific circuit breaker, getting the details right matters. The ABB TED124015WL Circuit Breaker is a 15-amp, 2-pole thermal magnetic molded-case circuit breaker (MCCB) from ABB's TED series and E150 frame family. Designed for compatible electrical equipment, this breaker features a non-interchangeable trip unit, fixed long-time and instantaneous protection, and factory-included copper/aluminum (Cu/Al) line and load lugs. ABB identifies the device as a 480 VAC / 250 VDC breaker, with published interrupting ratings for several AC and DC system voltages.
Key Features and Benefits
- 15-Amp Current Rating: Provides a defined 15A rating for compatible circuits and electrical assemblies designed to use this breaker.
- Two-Pole Construction: Features a two-pole configuration for equipment that requires this arrangement.
- ABB TED Series: Maintains the manufacturer's TED-series identification for accurate replacement matching.
- E150 Frame: Belongs to ABB's E150 molded-case circuit breaker family, an important consideration for equipment compatibility.
- Thermal Magnetic Protection: Combines thermal overload protection with magnetic instantaneous fault protection.
- Fixed LI Trip Function: Includes fixed long-time and instantaneous protective functions, as specified by ABB.
- Non-Interchangeable Trip Style: Features a non-interchangeable trip configuration that must match the requirements of the existing equipment.
Technical Specifications
-
Manufacturer: ABB
-
Catalog Number: TED124015WL
-
UPC: 783164067972
-
Product Type: Molded-Case Circuit Breaker (MCCB)
-
Series: TED
-
Product Family: E150
-
Frame Type: E150
-
Category: Thermal Magnetic
-
Product Line: Thermal Magnetic
-
Manufacturer Description: 2 POLE 480VAC 250VDC 15A BREAKER
-
Rated Current: 15 Amps
-
Number of Poles: 2
-
Trip Style: Non-Interchangeable
-
Trip Function: LI (Long-Time and Instantaneous)
-
Long-Time Trip: Fixed
-
Instantaneous Trip: Fixed
-
Continuous Current Rating Classification: Standard
-
Suitable for Reverse Feed: Yes
-
Line and Load Lugs: Included – Copper/Aluminum (Cu/Al)
-
Lug References: TC041, TCAL14
-
Special Marking: HACR
-
Current Metering: No
-
Protective Relays: No
-
GO Schedule: EB
-
GSA Compliance: Yes
-
UL File Number: E11592
-
CSA File Number: LR57114
-
Environmental Product Declaration: No Declaration Needed
Material Compliance and Certifications
For electrical maintenance and replacement work, documented product classifications and certification references help identify the device being evaluated.
- ABB publishes the following information for the TED124015WL E150 Thermal Magnetic Circuit Breaker.
- UL File Number: E11592
- CSA File Number: LR57114
Where It Works Best
The ABB TED124015WL 15 Amp, 2 Pole Circuit Breaker is particularly relevant when maintaining established electrical equipment that specifies this exact breaker or expressly approves its use. Its E150 frame, fixed LI trip function, documented AC/DC voltage ratings, and included Cu/Al line and load lugs give maintenance personnel a defined set of characteristics to evaluate.
Potential applications, when approved for the specific equipment and circuit, include:
- Legacy Electrical Distribution Systems
- Commercial Electrical Equipment
- Industrial Control and Distribution Assemblies
- Facility Maintenance Programs
- Electrical Equipment Restoration
- AC Circuit Protection
- DC Circuit Protection
- HACR-Related Equipment
- Reverse-Feed Applications
