GENERAL ELECTRIC

TEB132090 **Older Style** - 90Amp Circuit Breaker

TEB132090 **Older Style** - 90Amp Circuit Breaker

Regular price $675.00 USD
Regular price Sale price $675.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB132090 **Older Style** - 90Amp Circuit Breaker

When your existing electrical system needs a replacement circuit breaker, getting the details right matters. The TEB132090 Black Face Circuit Breaker is a 90-amp, three-pole molded case industrial circuit breaker designed for compatible electrical assemblies requiring a TEB-series breaker with an E150 frame and bolt-on connection. Equipped with a non-interchangeable thermal-magnetic trip unit, this breaker provides overload and short-circuit protection according to its specified ratings. Its bolt-on line-side connection and included load-side lugs make it particularly important to match the original equipment's mounting and wiring arrangement.

Key Features and Benefits

  • 90-Amp Current Rating: Provides a specified 90-amp rating for electrical circuits and equipment designed to accommodate this breaker.
  • Three-Pole Configuration: Designed for compatible electrical assemblies requiring three-pole circuit protection.
  • Bolt-On Line-Side Connection: Features a bolt-on connection for equipment specifically designed to accept this mounting and electrical connection style.
  • Load-Side Lugs Included: Provides the specified load-side cable termination points without implying that line-side cable lugs are included.
  • Thermal-Magnetic Trip Protection: Combines thermal overload response with magnetic short-circuit response.
  • Non-Interchangeable Trip Unit: Uses an integrated trip mechanism that is not designed for independent replacement with another trip unit.

Technical Specifications

  • Part Number: TEB132090
  • Series/Type: TEB
  • Product Category: Molded Case Industrial Circuit Breaker
  • Frame Size: E150
  • Face Color: Black
  • Amperage: 90 Amps
  • Number of Poles: 3
  • AIC Rating: 10,000 Amps (10k AIC)
  • AIC Reference Voltage: 240VAC
  • Connection Type: Bolt-On
  • Line-Side Connection: Bolt-On
  • Load-Side Connection: Cable Lugs
  • Included Lugs: Load-Side Lugs
  • Trip Mechanism: Thermal-Magnetic
  • Trip Unit: Non-Interchangeable
  • Construction: Molded Case
  • Height/Length: 6.31 Inches
  • Width: 4.13 Inches
  • Depth: 3.38 Inches
  • Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
  • Shipping Weight: 6.50 lbs.

Material Compliance and Certifications

The supplied product information does not verify UL listing, CSA certification, or RoHS compliance. Check the actual breaker's markings and applicable manufacturer documentation to confirm its certification status, equipment approvals, and installation requirements.

Where It Works Best

Common Applications:

  • Legacy Electrical Distribution Systems
  • Industrial Electrical Equipment
  • Commercial Power Distribution
  • Bolt-On Breaker Installations
  • Existing Electrical Panel Assemblies
  • Industrial Control Assemblies
  • Facility Electrical Maintenance
