TEB132080WL **Older Style** - 80Amp Circuit Breaker
TEB132080WL **Older Style** - 80Amp Circuit Breaker
Couldn't load pickup availability
TEB132080WL **Older Style** - 80Amp Circuit Breaker
Finding the right replacement circuit breaker means looking beyond the amperage rating. The way a breaker connects to an electrical system, its frame size, and its protective characteristics all matter when you're maintaining existing equipment. The TEB132080WL Black Face Circuit Breaker is an 80-amp, three-pole molded-case industrial circuit breaker with an E150 frame, cable-in/cable-out (lug-lug) connections, and a non-interchangeable thermal-magnetic trip unit. It's intended for compatible industrial and commercial electrical assemblies that require this specific configuration, helping preserve the original form, fit, and protective function of established electrical systems.
Key Features and Benefits
- 80-Amp Current Rating: Provides an 80-amp rating for compatible electrical circuits and equipment requiring this level of circuit protection.
- Three-Pole Configuration: Designed for electrical assemblies that require a three-pole molded case circuit breaker.
- Cable-In/Cable-Out Connections: Features a lug-lug arrangement for cable terminations on both the incoming and outgoing sides.
- Line and Load-Side Lugs Included: Comes with lugs on both sides, matching the specified terminal configuration.
- Thermal-Magnetic Trip Protection: Combines thermal overload protection with magnetic short-circuit response.
- Non-Interchangeable Trip Unit: Incorporates a trip mechanism that is not designed to be exchanged independently for a different trip unit.
Technical Specifications
-
Part Number: TEB132080WL
-
Series/Type: TEB
-
Product Category: Molded Case Industrial Circuit Breaker
-
Frame Size: E150
-
Face Color: Black
-
Amperage: 80 Amps
-
Number of Poles: 3
-
AIC Rating: 10,000 Amps (10k AIC)
-
AIC Reference Voltage: 240VAC
-
Connection Type: Cable-In/Cable-Out (Lug-Lug)
-
Line-Side Connection: Cable Lug
-
Load-Side Connection: Cable Lug
-
Included Lugs: Line-Side and Load-Side Lugs
-
Trip Mechanism: Thermal-Magnetic
-
Trip Unit: Non-Interchangeable
-
Construction: Molded Case
-
Height/Length: 6.31 Inches
-
Width: 4.13 Inches
-
Depth: 3.38 Inches
-
Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
-
Shipping Weight: 6.50 lbs.
Material Compliance and Certifications
The available product information does not verify UL listing, CSA certification, or RoHS compliance. Consult the breaker's markings and applicable manufacturer documentation to confirm required certifications, listings, and equipment approvals.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Systems
- Industrial Power Distribution Equipment
- Commercial Electrical Installations
- Cable-In/Cable-Out Installations
- Existing Electrical Panel Assemblies
- Industrial Control Equipment
- Facility Electrical Maintenance
