TEB132070WL - 70Amp Circuit Breaker

TEB132070WL - 70Amp Circuit Breaker

The TEB132070WL is a 3-pole, 70-amp molded case circuit breaker designed for your industrial and commercial electrical distribution systems requiring dependable circuit protection. Built on the E150 frame, this Type TEB breaker features a non-interchangeable thermal magnetic trip unit that helps you protect electrical equipment and conductors from overloads and short circuits. Its cable-in/cable-out (lug-lug) configuration includes both line-side and load-side lugs, making it suitable for applications where direct cable terminations are required. Designed for form, fit, and functional replacement in compatible systems, the TEB132070WL is built to last and helps you to maintain the safe operation of existing electrical installations while meeting its specified electrical ratings.

Key Features and Benefits

• 70 Amp Current Rating: 70 Amp current rating for commercial and industrial power distribution applications.
• 3-Pole Configuration: 3-pole configuration for protecting three-phase electrical circuits.
• Type TEB Circuit Breaker: Type TEB molded case circuit breaker.
• E150 Frame Construction: E150 frame construction.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit provides protection against overloads and short circuits.
• Cable-In/Cable-Out Design: Cable-in/Cable-out (Lug-Lug) design simplifies direct conductor termination.
• Included Accessories: Includes both line-side and load-side lugs.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 240VAC.
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible equipment.
• Built to Last: Built to last for long-term service in properly maintained electrical systems.


Technical Specifications

• Part Number: TEB132070WL

• Type: TEB

• Frame: E150

• Circuit Breaker Type: Molded Case Industrial Circuit Breaker

• Poles: 3

• Amperes: 70A

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Interrupting Capacity: 10kA @ 240VAC

• Voltage Rating: 240VAC

• Connection Type: Cable-in/Cable-out (Lug-Lug)

• Included Accessories: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Construction: Molded case circuit breaker designed for industrial electrical distribution applications.
• Thermal Magnetic Protection: Thermal magnetic trip mechanism provides overload and short-circuit protection based on the manufacturer's design specifications.
• Interrupting Rating: Rated for 10kA interrupting capacity at 240VAC.
• Installation Requirements: Verify compatibility with your electrical system and applicable local electrical codes before installation.


Where It Works Best

• The TEB132070WL is well suited for industrial facilities, commercial buildings, manufacturing operations, and other three-phase electrical systems that require a 70-amp, 3-pole molded case circuit breaker. Its lug-lug configuration makes it a practical choice for installations requiring direct cable connections, while the E150 frame and thermal magnetic trip unit make it an appropriate form, fit, and functional replacement in compatible switchboards, panelboards, motor control equipment, and distribution systems.
