TEB132070 - 70Amp Circuit Breaker

TEB132070 - 70Amp Circuit Breaker

The TEB132070 is a 3-pole, 70 amp bolt-on molded case circuit breaker designed for use in your commercial and industrial electrical distribution systems requiring dependable overcurrent and short-circuit protection. Built on the E150 frame, this breaker features a non-interchangeable thermal magnetic trip unit that provides both inverse-time overload protection and instantaneous protection against short circuits. Its bolt-on mounting design helps you to provide a secure installation in compatible panelboards and switchboards, making it well suited for maintaining or replacing existing equipment while preserving proper form, fit, and function.

Rated 10kA at 240VAC, the TEB132070 is intended for branch circuit protection in a variety of applications where reliable circuit interruption is essential. This breaker includes load-side lugs, helping you simplify installation and conductor termination. Built to last, it is a practical choice for maintaining existing electrical systems in manufacturing facilities, commercial buildings, institutional properties, and other industrial environments where compatible TEB-series breakers are specified.

Key Features and Benefits

• 70 Amp Current Rating: 70 Amp continuous current rating.
• Three-Pole Configuration: Three-pole configuration for three-phase electrical systems.
• Bolt-On Mounting: Bolt-on mounting design for secure installation in compatible equipment.
• E150 Frame Construction: E150 frame molded case circuit breaker.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit for overload and short-circuit protection.
• 10kA Interrupting Capacity: Rated 10kA interrupting capacity at 240VAC.
• Included Load-Side Lugs: Includes load-side lugs for convenient field installation.
• Form, Fit, and Functional Replacement: Designed for form, fit, and functional replacement in compatible legacy electrical systems.
• Built to Last: Built to last for demanding commercial and industrial applications.


Technical Specifications

• Part Number: TEB132070

• Type: TEB

• Frame: E150

• Circuit Breaker Type: Molded Case Industrial Circuit Breaker

• Mounting Style: Bolt-On

• Poles: 3

• Amperage: 70 Amps

• Interrupting Rating: 10kA @ 240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Line/Load Connection: Includes Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for molded case circuit breakers.
• Thermal Magnetic Protection: Thermal magnetic protection provides overload and instantaneous short-circuit protection within the breaker's designed ratings.
• Equipment Compatibility: Suitable for use only in equipment designed to accept compatible TEB E150 frame circuit breakers.
• Installation Requirements: Installation should be performed in accordance with applicable electrical codes and manufacturer requirements.


Where It Works Best

• The TEB132070 is well suited for commercial and industrial electrical distribution systems that require a compatible 70 amp, 3-pole bolt-on molded case circuit breaker. Common applications include:
  • Commercial buildings
  • Industrial manufacturing facilities
  • Distribution panels
  • Panelboards
  • Switchboards
  • Mechanical equipment
  • HVAC systems
  • Pumps and motor circuits
  • Facility maintenance and electrical system repairs requiring a compatible TEB-series replacement
