TEB132040WL - 40Amp Circuit Breaker

TEB132040WL - 40Amp Circuit Breaker

The TEB132040WL is a 3-pole, 40-amp molded case circuit breaker built on the E150 frame and designed for use in your commercial and industrial power distribution systems. It features a non-interchangeable thermal magnetic trip unit, which responds to both overloads and short circuits to help you protect connected equipment. This model uses a cable-in/cable-out (lug-lug) configuration and comes with line- and load-side lugs already included, making installation straightforward in compatible equipment. Built to last, the TEB132040WL is intended as a form, fit, and functional replacement for existing TEB series breakers in systems that require the same electrical ratings and physical configuration.

Key Features and Benefits

• 40 Amp Current Rating: 40 Amp current rating.
• Three-Pole Design: Three-pole molded case circuit breaker.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 240VAC.
• E150 Frame Construction: E150 frame construction.
• Thermal Magnetic Trip Unit: Fixed (non-interchangeable) thermal magnetic trip unit.
• Cable-In/Cable-Out Connection: Cable-in/cable-out (lug-lug) connection style.
• Included Lugs: Includes both line-side and load-side lugs.
• Built to Last: Built for long service life in commercial and industrial applications.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible TEB circuit breakers.


Technical Specifications

• Part Number: TEB132040WL

• Type: TEB

• Frame: E150

• Poles: 3

• Amperage: 40A

• Interrupting Rating: 10kA @ 240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-In / Cable-Out (Lug-Lug)

• Included Lugs: Line and Load Side

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Equipment Compatibility: The TEB132040WL is manufactured for use in compatible low-voltage electrical distribution equipment.
• Form, Fit, and Function: It is intended to match the original form, fit, and function of compatible installations.
• Installation Requirements: Always verify compatibility with your panel or equipment, as well as local electrical codes, before installation.


Where It Works Best

• This breaker is commonly used in commercial buildings, industrial facilities, manufacturing equipment, and electrical distribution systems that require a 3-pole, 40-amp breaker with a 10kA rating at 240VAC. The included lugs make it a practical choice for applications using direct cable terminations, including switchboards, panelboards, motor control equipment, and OEM machinery.
