TEB132030 - 30Amp Circuit Breaker

TEB132030 - 30Amp Circuit Breaker

The TEB132030 is a 3-pole, 30-amp molded-case circuit breaker designed for use in your electrical distribution systems that require dependable branch-circuit protection. Built on the E150 frame, this Type TEB bolt-on circuit breaker features a non-interchangeable thermal magnetic trip unit, protecting against both overloads and short circuits. With a 10 kA interrupting rating at 240 VAC, it is well-suited for your commercial and industrial applications where compatibility with existing equipment is essential. This breaker includes load-side lugs to simplify installation and is designed for long service life in properly maintained electrical systems. When you replace an existing breaker, the TEB132030 offers the proper form, fit, and function for compatible panelboards and distribution equipment.

Key Features and Benefits

• 30 Amp Current Rating: 30 Amp current rating for branch circuit protection.
• 3-Pole Configuration: 3-pole configuration for three-phase electrical systems.
• Type TEB Design: Type TEB design for compatibility with designated equipment.
• E150 Frame Construction: E150 frame construction.
• Bolt-On Mounting: Bolt-on mounting for a secure installation.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit helps protect against overloads and short circuits.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 240VAC.
• Included Load-Side Lugs: Includes load-side lugs for added installation convenience.
• Built to Last: Built to last when installed and maintained according to manufacturer's specifications.


Technical Specifications

• Part Number: TEB132030

• Type: TEB

• Frame: E150

• Circuit Breaker Type: Molded Case Industrial Circuit Breaker

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Mounting Style: Bolt-On

• Poles: 3

• Current Rating: 30 Amps

• Interrupting Rating: 10kA @ 240VAC

• Voltage Rating: 240VAC

• Included Accessories: Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Industry Standards: Manufactured for use in accordance with applicable industry standards for molded case circuit breakers.
• Thermal Magnetic Trip Design: The thermal magnetic trip design provides overcurrent protection through both thermal overload and magnetic short-circuit response.
• Installation Requirements: Verify compatibility with your electrical system and local electrical code requirements before installation.


Where It Works Best

• The TEB132030 is commonly used in commercial buildings, industrial facilities, manufacturing operations, and electrical distribution systems that utilize compatible Type TEB panelboards or switchboards. It is an excellent choice when maintaining or replacing an existing breaker in legacy equipment where matching the original form, fit, and electrical ratings is important. Its bolt-on design and included load-side lugs make it well-suited for applications requiring a secure connection and dependable circuit protection.
