GENERAL ELECTRIC
TEB132020WL **Older Style** - 20Amp Circuit Breaker
TEB132020WL **Older Style** - 20Amp Circuit Breaker
Couldn't load pickup availability
TEB132020WL **Older Style** - 20Amp Circuit Breaker
Finding the right circuit breaker for your existing electrical system means looking beyond amperage. The TEB132020WL Black Face Circuit Breaker is a 20-amp, 3-pole molded-case industrial circuit breaker featuring a TEB series E150 frame, cable-in/cable-out (lug-lug) connection configuration, and a non-interchangeable thermal-magnetic trip unit. With a 10 kA interrupting rating at 240VAC, this breaker provides overload and short-circuit protection for compatible electrical equipment. Its black-face design and specific frame dimensions make it a practical consideration when replacing a matching breaker in an established electrical installation.
Key Features and Benefits
- 20 Amp Current Rating: Provides a 20-amp rating for electrical circuits and equipment requiring this specific level of overcurrent protection.
- 3 Pole Configuration: Features three protected poles for electrical applications that require a three-pole circuit breaker arrangement.
- Black Face Design: Features the recognizable black-face appearance associated with this TEB breaker style, helping distinguish it during equipment identification and replacement.
- Cable-In/Cable-Out Connection: Features a lug-lug configuration with cable connections on both the line and load sides, intended for compatible electrical equipment.
Technical Specifications
-
Part Number: TEB132020WL
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Black Face
-
Amperage: 20 Amps
-
Number of Poles: 3
-
Voltage Rating: 240VAC (Specified Interrupting Rating Voltage)
-
Interrupting Capacity: 10k AIC (10,000 Amps) at 240VAC
-
Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
-
Line-Side Connection: Cable Lug
-
Load-Side Connection: Cable Lug
-
Line-Side Lugs: Included
-
Load-Side Lugs: Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit: Non-Interchangeable
-
Width: 4.13 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
-
Shipping Weight: 6.50 lbs.
Material Compliance and Certifications
The TEB132020WL molded case circuit breaker features an enclosed E150 frame assembly with a non-interchangeable thermal-magnetic trip unit.
Where It Works Best
- Legacy Electrical Distribution Equipment
- Industrial Control and Power Equipment
- Commercial Electrical Systems
- Facility Maintenance and Electrical Repairs
- Three-Pole Circuit Protection Applications
- Cable-In/Cable-Out Electrical Installations
- E150 Frame Circuit Breaker Replacement
