TEB132020WL - 20Amp Circuit Breaker

TEB132020WL - 20Amp Circuit Breaker

The TEB132020WL is a 3-pole, 20-amp molded case circuit breaker built on the E150 frame for your commercial and industrial power distribution systems. It uses a non-interchangeable thermal-magnetic trip unit that helps protect electrical circuits from overloads and short circuits during normal operation. This model features a cable-in/cable-out (lug-lug) configuration and includes line-side and load-side lugs, making it suitable for installations that require this connection style. With a 10kA interrupting rating at 240VAC, the TEB132020WL is intended as a form, fit, and functional replacement for compatible equipment where matching the original breaker's ratings and physical configuration is important. Built to last, it is a dependable choice for maintaining existing electrical systems without changing the original design.

Key Features and Benefits

• 20 Amp Current Rating: 20 Amp current rating.
• Three-Pole Design: Three-pole design for three-phase circuits.
• E150 Frame Construction: E150 frame construction.
• 10kA Interrupting Rating: 10kA interrupting rating at 240VAC.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit.
• Cable-In/Cable-Out Configuration: Cable-in/cable-out (lug-lug) configuration.
• Included Lugs: Includes both line-side and load-side lugs.
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible equipment.
• Built to Last: Built to last for commercial and industrial service.


Technical Specifications

• Part Number: TEB132020WL

• Type: TEB

• Frame: E150

• Circuit Breaker Style: Molded Case Industrial Circuit Breaker

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Poles: 3

• Amperage: 20 A

• Voltage Rating: 240 VAC

• Interrupting Capacity: 10kA @ 240VAC

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• Included: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Product Design: The TEB132020WL is manufactured for use in compatible electrical distribution equipment and is designed to meet its original electrical ratings. The thermal magnetic trip unit provides overload and short-circuit protection as intended by the product design.
• Installation: Always verify compatibility with your equipment and follow applicable electrical codes and manufacturer requirements before installation.


Where It Works Best

• The TEB132020WL is commonly used in commercial and industrial electrical distribution equipment, including switchboards, panelboards, motor control equipment, and machinery that requires a 3-pole, 20-amp E150 frame circuit breaker. It is well-suited for applications where maintaining the original form, fit, and function of the installed breaker is important.
