GENERAL ELECTRIC
TEB132020 **Older Style** - 20Amp Circuit Breaker
TEB132020 **Older Style** - 20Amp Circuit Breaker
Couldn't load pickup availability
TEB132020 **Older Style** - 20Amp Circuit Breaker
When you're maintaining an established electrical system, you need a circuit breaker with the right specifications. The TEB132020 Black Face Circuit Breaker is a 20-amp, 3-pole, bolt-on molded-case industrial circuit breaker designed for compatible electrical equipment requiring a TEB series, E150 frame configuration. With a non-interchangeable thermal-magnetic trip unit, a 10 kA interrupting rating at 240VAC, and included load-side lugs, this breaker provides the electrical characteristics needed for specific industrial and commercial applications. Its familiar black-face design and defined mounting arrangement make it a practical choice when you need to match an existing breaker in form, fit, and function.
Key Features and Benefits
- 20 Amp Current Rating: Designed for compatible circuits requiring a 20-amp molded-case circuit breaker.
- 3 Pole Configuration: Provides three protected poles for electrical applications that require this arrangement.
- Black Face Design: Features the recognizable black-face appearance associated with this breaker style, helping distinguish it during component identification.
- Bolt-On Connection: Uses a bolt-on line-side connection arrangement for equipment designed to accept this configuration.
- Load-Side Lugs Included: Comes with load-side lugs for the designated cable termination points.
Technical Specifications
-
Part Number: TEB132020
-
Product Name: TEB132020 Black Face Circuit Breaker
-
Product Category: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Black Face
-
Amperage: 20 Amps
-
Number of Poles: 3
-
Voltage Rating: 240VAC
-
Interrupting Capacity (AIC): 10 kA (10,000 Amps) at 240VAC
-
Connection Configuration: Bolt-On
-
Line-Side Connection: Bolt-On
-
Load-Side Connection: Cable Lugs
-
Load-Side Lugs: Included
-
Line-Side Lugs: Not specified as included; bolt-on line-side configuration
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit: Non-Interchangeable
-
Width: 4.13 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
-
Shipping Weight: 6.50 lbs.
Material Compliance and Certifications
The TEB132020 is a molded-case industrial circuit breaker with an integrated, non-interchangeable thermal-magnetic trip unit. Its molded enclosure houses the internal switching and protective components used in the breaker's intended electrical application.
The supplied product information does not independently confirm individual UL listing, CSA certification, RoHS compliance, or other certification status for this particular breaker.
Where certification or regulatory compliance is required, the installing professional should review the actual device markings and applicable manufacturer records. The breaker's suitability also depends on the requirements of the equipment it will be installed in.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Equipment
- Industrial Electrical Panels
- Commercial Electrical Systems
- Facility Maintenance
- Industrial Control Equipment
- Electrical Equipment Repairs
