GENERAL ELECTRIC

TEB132015WL **Older Style** - 15Amp Circuit Breaker

TEB132015WL **Older Style** - 15Amp Circuit Breaker

Regular price $250.00 USD
Regular price Sale price $250.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB132015WL **Older Style** - 15Amp Circuit Breaker

Finding the right circuit breaker for your existing electrical system comes down to matching the key details. The TEB132015WL Black Face Circuit Breaker is a 15-amp, 3-pole molded-case industrial circuit breaker with a TEB series E150 frame, cable-in/cable-out (lug-lug) connection configuration, and a non-interchangeable thermal-magnetic trip unit.

Key Features and Benefits

  • 15 Amp Current Rating: Provides the specified 15-amp rating for compatible electrical circuits and equipment.
  • 3 Pole Configuration: Features three protected poles for applications requiring this particular breaker arrangement.
  • Black Face Design: Features the recognizable black-face appearance associated with this TEB breaker style.
  • Cable-In/Cable-Out (Lug-Lug) Configuration: Uses cable lug connections on both the line and load sides for equipment designed to accommodate this electrical interface.
  • Line and Load-Side Lugs Included: Supplied with lugs on both sides to accommodate the specified cable termination arrangement.
  • 240VAC Voltage Rating: Intended for electrical installations where the specified voltage rating is appropriate.
  • Thermal Magnetic Protection: Combines thermal overload and magnetic short-circuit protection through a non-interchangeable trip unit.

Technical Specifications

  • Part Number: TEB132015WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame: E150
  • Face Style: Black Face
  • Amperage: 15 Amps
  • Number of Poles: 3
  • Voltage Rating: 240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 240VAC
  • Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Connection: Cable Lug
  • Load-Side Connection: Cable Lug
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 4.13 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
  • Shipping Weight: 6.50 lbs.

Material Compliance and Certifications

The TEB132015WL molded-case circuit breaker includes a non-interchangeable thermal-magnetic trip unit within an enclosed breaker assembly. Its molded-case construction houses the internal switching and protective components for the breaker's intended electrical application.

The exact material composition of the enclosure and internal components has not been independently confirmed. Similarly, the supplied specifications do not establish the breaker's individual UL listing, CSA certification, or RoHS compliance status. Verify any required certifications, conductor compatibility, and installation approvals against the breaker's markings and applicable manufacturer documentation before installation.

Where It Works Best

Common Applications:

  • Legacy Electrical Distribution Equipment
  • Industrial Control and Power Equipment
  • Commercial Electrical Systems
  • Facility Maintenance and Electrical Repairs
  • Three-Pole Circuit Protection Applications
  • Component Replacement in Established Equipment
