TEB132015WL - 15Amp Circuit Breaker

TEB132015WL - 15Amp Circuit Breaker

The TEB132015WL is a 3-pole, 15 Amp molded case circuit breaker designed for protecting your electrical distribution systems from overloads and short circuits. Built on the E150 frame, this breaker uses a non-interchangeable thermal magnetic trip unit that reacts to both sustained overload conditions and sudden fault currents. It features a cable-in/cable-out (lug-lug) design and comes with line- and load-side lugs already included, making it a convenient option when replacing a compatible breaker in an existing installation. Rated for 10kA at 240VAC, the TEB132015WL is intended for use in your industrial and commercial equipment that requires these electrical ratings. Matching the correct frame, pole count, amp rating, and connection style is important when servicing existing systems, and this breaker is built to provide the proper form, fit, and function for compatible applications. Its durable molded case construction is made for years of dependable service in demanding electrical environments.

Key Features and Benefits

• 15 Amp Current Rating: 15 Amp current rating.
• Three-Pole Configuration: Three-pole configuration for three-phase systems.
• 10kA Interrupting Rating: 10kA interrupting rating at 240VAC.
• E150 Frame Design: E150 frame design.
• Non-Interchangeable Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit.
• Cable-In/Cable-Out Configuration: Cable-in/cable-out (lug-lug) configuration.
• Line-Side and Load-Side Lugs Included: Includes both line-side and load-side lugs.
• Molded Case Construction: Molded case construction is built for long service life.
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible equipment.


Technical Specifications

• Part Number: TEB132015WL

• Type: TEB

• Frame: E150

• Circuit Breaker Type: Molded Case Industrial Circuit Breaker

• Poles: 3

• Amperage: 15 Amps

• Voltage Rating: 240VAC

• Interrupting Rating: 10kA @ 240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-in/Cable-out (Lug-Lug)

• Included Accessories: Line- and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 4.13 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Circuit Breaker: Molded case circuit breaker for industrial and commercial electrical systems.
• Thermal Magnetic Trip Unit: The thermal magnetic trip unit provides overload and short-circuit protection.
• Equipment Compatibility: Designed for use in equipment compatible with its published electrical ratings.
• Installation: Installation should be performed in accordance with applicable electrical codes and manufacturer requirements.


Where It Works Best

• The TEB132015WL is commonly used in commercial buildings, industrial facilities, manufacturing equipment, control panels, and electrical distribution systems that require a 3-pole, 15 Amp TEB circuit breaker. It is a practical choice for maintaining existing equipment where the original electrical ratings, frame size, and lug configuration need to be matched.
