GENERAL ELECTRIC
TEB132015 **Older Style** - 15Amp Circuit Breaker
TEB132015 **Older Style** - 15Amp Circuit Breaker
Couldn't load pickup availability
TEB132015 **Older Style** - 15Amp Circuit Breaker
Finding the right replacement for your circuit breaker for an existing electrical system starts with the details. The TEB132015 Black Face Circuit Breaker is a 15-amp, 3-pole3-pole molded-case industrial circuit breaker with a TEB series E150 frame, bolt-on connection configuration, and non-interchangeable thermal-magnetic trip unit. Designed for use in compatible electrical equipment, this breaker provides overload and short-circuit protection while maintaining the specific physical and electrical characteristics required by certain established installations.
Key Features and Benefits
- 15 Amp Current Rating: Provides the specified 15 amp rating for compatible electrical circuits and equipment.
- 3 Pole Configuration: Features three protected poles for applications that require this breaker arrangement.
- Black Face Design: Features the recognizable black-face appearance that helps identify this TEB breaker style.
- Bolt-On Connection Configuration: Uses a bolt-on line-side connection arrangement intended for equipment designed to accommodate this mounting and electrical interface.
- Load-Side Lugs Included: Supplied with load-side lugs for conductor termination. Line-side cable lugs are not specified as included.
- 120/240VAC Voltage Rating: Intended for installations where the specified voltage rating is appropriate.
- Thermal Magnetic Protection: Combines thermal overload response with magnetic short-circuit response.
Technical Specifications
-
Part Number: TEB132015
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Black Face
-
Amperage: 15 Amps
-
Number of Poles: 3
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
-
Connection Configuration: Bolt-On
-
Line-Side Connection: Bolt-On
-
Load-Side Connection: Cable Lug
-
Line-Side Lugs: Not specified as included
-
Load-Side Lugs: Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit: Non-Interchangeable
-
Width: 4.13 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 4.13"W x 6.31"L x 3.38"D
-
Shipping Weight: 6.50 lbs.
Material Compliance and Certifications
The TEB132015 molded case circuit breaker incorporates a non-interchangeable thermal magnetic trip unit within an enclosed breaker assembly. Its molded-case construction houses the internal switching and protective components for the breaker's intended electrical application.
The exact material composition of the enclosure and internal components has not been independently confirmed. Similarly, the supplied specifications do not establish the breaker's individual UL listing, CSA certification, or RoHS compliance status.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Equipment
- Industrial Control and Power Equipment
- Commercial Electrical Systems
- Facility Maintenance and Electrical Repairs
- Three-Pole Circuit Protection Applications
- Component Replacement in Established Equipment
