GENERAL ELECTRIC

TEB122100WL **Older Style** - 100Amp Circuit Breaker

TEB122100WL **Older Style** - 100Amp Circuit Breaker

Regular price $394.29 USD
Regular price Sale price $394.29 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122100WL **Older Style** - 100Amp Circuit Breaker

When your existing electrical system needs a replacement breaker, getting the connection style right matters as much as matching the amperage. The TEB122100WL Older Style Black Face Circuit Breaker is a 100 amp, 2-pole molded-case industrial circuit breaker designed for compatible electrical equipment requiring a TEB series E150 frame with cable-in/cable-out (lug-lug) connections. Equipped with a non-interchangeable thermal-magnetic trip unit, this breaker combines overload and short-circuit protection in a single molded-case assembly. Its 120/240VAC voltage rating and 10k AIC interrupting capacity at 120/240VAC are essential checkpoints when evaluating the breaker for a legacy electrical installation.

Key Features and Benefits

  • 100 Amp Current Rating: Provides the specified 100 amp rating for compatible circuits and electrical equipment.
  • 2 Pole Configuration: Designed for installations requiring a two-pole molded case circuit breaker.
  • Older Style Black Face: Features the recognizable black-face appearance associated with this TEB model, helping with visual identification during replacement work.
  • TEB Series, E150 Frame: Identifies the breaker family and frame size for comparison with existing equipment requirements.
  • Cable-In/Cable-Out (Lug-Lug) Connections: Uses cable terminations on both the incoming line side and outgoing load side, rather than a bolt-on line-side connection.
  • Line-Side and Load-Side Lugs Included: Both sets of lugs are supplied, which is important for equipment requiring this connection configuration.
  • 120/240VAC Voltage Rating: Specified for electrical applications within the stated voltage rating.

Technical Specifications

  • Part Number: TEB122100WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 100 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Connection: Cable Lug
  • Load-Side Connection: Cable Lug
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122100WL molded case circuit breaker features an enclosed breaker assembly with a non-interchangeable thermal magnetic trip unit. Its molded-case construction is intended to house the switching and protective components for the breaker's specified application.

Do not assume specific UL listing, CSA certification, or RoHS compliance without checking the breaker's markings and applicable manufacturer documentation. If an installation requires a particular listing or equipment approval, verify those requirements before use.

Where It Works Best

Common Applications:

  • Legacy Electrical Distribution Systems
  • Industrial Electrical Equipment
  • Commercial Electrical Installations
  • Facility Maintenance and Repairs
  • Cable-In/Cable-Out Breaker Applications
  • Equipment Servicing and Component Replacement
