TEB122100WL - 100Amp Circuit Breaker

TEB122100WL - 100Amp Circuit Breaker

The TEB122100WL is a 2-pole, 100-amp molded case circuit breaker designed for use in 120/240VAC commercial and industrial electrical systems. Built on the E150 frame, it features a non-interchangeable thermal magnetic trip unit that helps protect electrical equipment from overloads and short circuits. This model uses a cable-in/cable-out (lug-lug) connection and comes with both line-side and load-side lugs already included. Whether you're replacing an existing breaker during maintenance or keeping an established electrical system in service, the TEB122100WL offers the same form, fit, and function expected for compatible TEB applications. Its molded case construction is built to last, making it a practical choice for facilities where dependable circuit protection is required.

Key Features and Benefits

• 100 Amp Current Rating: 100 Amp current rating.
• Two-Pole Configuration: Two-pole configuration.
• Rated for 120/240VAC Systems: Rated for 120/240VAC systems.
• 10kA Interrupting Capacity: 10kA interrupting capacity.
• E150 Frame Design: E150 frame design.
• Fixed Thermal Magnetic Trip Unit: Fixed (non-interchangeable) thermal magnetic trip unit.
• Cable-In/Cable-Out Connections: Cable-in/cable-out (lug-lug) connections.
• Line-Side and Load-Side Lugs Included: Includes both line-side and load-side lugs.
• Built to Last: Built to last in commercial and industrial environments.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible equipment.


Technical Specifications

• Part Number: TEB122100WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 100A

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• Included: Line-Side and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Circuit Breaker: Molded case circuit breaker for commercial and industrial applications.
• Thermal Magnetic Trip Unit: The thermal magnetic trip unit provides overload and short-circuit protection.
• Interrupting Rating: Rated for 10kA interrupting capacity at 120/240VAC.
• Installation: Always confirm compatibility with your equipment and applicable electrical codes before installation.


Where It Works Best

• The TEB122100WL is commonly used in commercial buildings, industrial facilities, machinery, distribution equipment, and control panels that require a 2-pole, 100-amp TEB molded case circuit breaker. It's intended for maintaining compatible electrical systems where matching the original electrical ratings, frame size, and connection style is important.
