GENERAL ELECTRIC
TEB122100 **Older Style** - 100Amp Circuit Breaker
TEB122100 **Older Style** - 100Amp Circuit Breaker
Couldn't load pickup availability
TEB122100 **Older Style** - 100Amp Circuit Breaker
Finding the right replacement circuit breaker involves more than matching the amperage printed on the front. The frame size, connection style, voltage rating, and interrupting capacity all matter, especially when you're maintaining an existing electrical installation. The TEB122100 Older Style Black Face Circuit Breaker is a 100 amp, 2-pole molded-case industrial circuit breaker with a TEB series E150 frame, bolt-on connection, and non-interchangeable thermal-magnetic trip unit.
Key Features and Benefits
- 100 Amp Current Rating: Provides the specified current rating for compatible electrical circuits requiring a 100-amp breaker.
- 2 Pole Design: Features two poles for electrical equipment designed around this configuration.
- Older-Style Black Face: Matches the recognizable face style of this TEB breaker model.
- Bolt-On Connection: Designed for compatible equipment that requires a bolt-on breaker connection.
- Load-Side Lugs Included: Includes lugs for the designated outgoing conductor connections.
- 120/240VAC Voltage Rating: Intended for applications within the specified voltage rating.
Technical Specifications
-
Part Number: TEB122100
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage: 100 Amps
-
Number of Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity: 10 kA (10,000 Amps) at 120/240VAC
-
Connection Configuration: Bolt-On
-
Load-Side Connection: Cable Lugs
-
Load-Side Lugs: Included
-
Line-Side Connection: Bolt-On
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit Type: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122100 molded case circuit breaker features a molded enclosure that contains its switching components and a non-interchangeable thermal-magnetic trip unit. Its construction supports the breaker's specified electrical protection functions within compatible equipment.
We have not independently verified the enclosure material composition, individual UL listing, CSA certification, or RoHS compliance from the supplied specifications. When certifications or approvals are required, confirm them through product markings and manufacturer documentation rather than assuming them.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Systems
- Industrial Electrical Equipment
- Commercial Electrical Installations
- Facility Maintenance and Repairs
- Bolt-On Breaker Replacement
- Electrical Equipment Servicing
