GENERAL ELECTRIC

TEB122090WL **Older Style** - 90Amp Circuit Breaker

TEB122090WL **Older Style** - 90Amp Circuit Breaker

Regular price $394.29 USD
Regular price Sale price $394.29 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122090WL **Older Style** - 90Amp Circuit Breaker

When you replace a circuit breaker in an existing electrical system, getting the details right matters; amperage is only part of the picture. The frame, mounting arrangement, terminal connections, and interrupting capacity must match the equipment's requirements. The TEB122090WL Older Style Black Face Circuit Breaker is a 90-amp, 2-pole molded-case industrial circuit breaker featuring a TEB series E150 frame, cable-in/cable-out (lug-lug) configuration, and a non-interchangeable thermal-magnetic trip unit. Designed for compatible legacy electrical equipment, it offers the specific electrical ratings and physical characteristics needed for applications requiring this breaker model.

Key Features and Benefits

  • 90 Amp Current Rating: Designed for compatible electrical circuits that require a 90-amp molded case circuit breaker.
  • 2 Pole Configuration: Provides two-pole circuit protection in equipment designed for this arrangement.
  • Older Style Black Face: Features the recognizable face style associated with this TEB breaker configuration.
  • Cable-In/Cable-Out (Lug-Lug) Configuration: Provides cable termination connections on both the incoming and outgoing sides of the breaker.
  • Line-Side and Load-Side Lugs Included: Includes lugs for both the designated conductor connections.
  • 120/240VAC Voltage Rating: Intended for electrical applications within the specified voltage rating.
  • Thermal Magnetic Trip Mechanism: Combines thermal overload protection with magnetic short-circuit protection.

Technical Specifications

  • Part Number: TEB122090WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 90 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Connection: Cable Lug
  • Load-Side Connection: Cable Lug
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit Type: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122090WL molded case circuit breaker features a molded enclosure that contains its switching components and an integrated thermal-magnetic trip mechanism. The non-interchangeable trip unit provides the specified overload and short-circuit protection functions within the breaker assembly.

The available specifications identify this breaker as a TEB series E150 frame, 90 amp, 2-pole device rated for 120/240VAC with 10 kAIC at 120/240VAC. The supplied information does not verify specific housing materials, individual UL listing, CSA certification, or RoHS compliance. Confirm any required certifications, approvals, or material compliance claims through the actual product markings and manufacturer documentation.

Where It Works Best

Common Applications:

  • Legacy Electrical Distribution Equipment
  • Industrial Electrical Systems
  • Commercial Electrical Installations
  • Facility Maintenance and Repair
  • Cable-In/Cable-Out Breaker Applications
  • Electrical Equipment Servicing
