TEB122090 **Older Style** - 90Amp Circuit Breaker
TEB122090 **Older Style** - 90Amp Circuit Breaker
Couldn't load pickup availability
TEB122090 **Older Style** - 90Amp Circuit Breaker
Finding the right circuit breaker for an older electrical system isn't just about matching the amperage. The frame size, mounting arrangement, voltage rating, and terminal configuration must match the equipment you're servicing. The TEB122090 Older Style Black Face Circuit Breaker is a 90-amp, 2-pole molded-case industrial circuit breaker featuring a TEB series E150 frame, bolt-on configuration, and non-interchangeable thermal-magnetic trip unit. Designed for compatible legacy electrical installations, this breaker provides the specified electrical protection characteristics and physical configuration required for equipment that needs this model.
Key Features and Benefits
- 90 Amp Current Rating: Designed for compatible electrical circuits requiring a 90-amp molded case circuit breaker.
- 2 Pole Configuration: Provides two-pole circuit protection in electrical equipment designed for this arrangement.
- Older Style Black Face: Features the recognizable face design associated with this TEB breaker configuration.
- Bolt-On Configuration: Designed for electrical assemblies requiring this particular line-side mounting and connection arrangement.
- Load-Side Lugs Included: Provides the designated termination points for outgoing conductors.
- 120/240VAC Voltage Rating: Intended for applications within the specified voltage rating.
- Thermal Magnetic Trip Mechanism: Combines thermal overload protection with magnetic short-circuit protection.
Technical Specifications
-
Part Number: TEB122090
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage: 90 Amps
-
Number of Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
-
Connection Configuration: Bolt-On
-
Line-Side Connection: Bolt-On
-
Load-Side Lugs: Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit Type: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122090 molded case circuit breaker features a molded enclosure that contains its switching components and an integrated thermal-magnetic trip mechanism. Its non-interchangeable trip unit provides the specified overload and short-circuit protection functions within the breaker assembly.
Where It Works Best
- Legacy Electrical Distribution Equipment
- Industrial Electrical Systems
- Commercial Electrical Installations
- Facility Maintenance and Repair
- Bolt-On Circuit Breaker Applications
