GENERAL ELECTRIC

TEB122080WL **Older Style** - 80Amp Circuit Breaker

TEB122080WL **Older Style** - 80Amp Circuit Breaker

Regular price $394.29 USD
Regular price Sale price $394.29 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122080WL **Older Style** - 80Amp Circuit Breaker

When you're maintaining an older electrical system, start by matching the details that matter to find the right replacement circuit breaker. The TEB122080WL Older Style Black Face Circuit Breaker is an 80 amp, 2-pole molded-case industrial circuit breaker with a TEB series E150 frame, cable-in/cable-out (lug-lug) connection configuration, and a non-interchangeable thermal-magnetic trip unit. Designed for compatible legacy electrical equipment, this breaker provides the specified electrical protection characteristics and physical arrangement for installations requiring this model.

Key Features and Benefits

  • 80 Amp Current Rating: Designed for compatible electrical circuits that require an 80-amp molded case circuit breaker.
  • 2 Pole Configuration: Provides two-pole circuit protection in equipment designed for this arrangement.
  • Older Style Black Face: Helps identify the correct breaker style when matching existing electrical components.
  • Cable-In/Cable-Out (Lug-Lug) Configuration: Provides cable connection arrangements on both the incoming and outgoing sides.
  • Line-Side Lugs Included: Supplies the designated connection points for incoming conductors.
  • Load-Side Lugs Included: Supplies the designated connection points for outgoing conductors.
  • 120/240VAC Voltage Rating: Designed for applications within the specified voltage rating.
  • Thermal-Magnetic Trip Mechanism: Combines thermal overload and magnetic short-circuit protection.

Technical Specifications

  • Part Number: TEB122080WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 80 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit Type: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122080WL molded case circuit breaker features a molded enclosure and an integrated, non-interchangeable thermal magnetic trip unit. Its construction combines the specified switching and circuit-protection functions in a single breaker assembly.

The available specifications identify the breaker as a TEB series E150 frame, 80 amp, 2-pole device rated for 120/240VAC with 10 kAIC at 120/240VAC. The supplied information does not verify the exact molded housing materials, specific UL listing, CSA certification, or RoHS compliance. Confirm any required certification through the actual product markings and relevant manufacturer documentation.

Where It Works Best

Common Applications:

  • Legacy Electrical Distribution Equipment
  • Industrial Electrical Systems
  • Commercial Electrical Installations
  • Facility Maintenance and Repair
  • Cable-In/Cable-Out Circuit Breaker Applications
  • Electrical Equipment Servicing
