TEB122080WL - 80Amp Circuit Breaker

TEB122080WL - 80Amp Circuit Breaker

The TEB122080WL is a 2-pole, 80-amp molded-case circuit breaker for use in your commercial and industrial electrical distribution systems. Built on the E150 frame, this breaker has a non-interchangeable thermal magnetic trip unit that helps you protect circuits from overloads and short circuits. It carries a 10k A.I.C. rating at 120/240VAC and is configured with cable-in/cable-out (lug-lug) connections. Both the line-side and load-side lugs are included. When you're replacing an existing breaker, matching the original electrical ratings and physical configuration is just as important as the amp rating. The TEB122080WL is designed as a form, fit, and functional replacement for compatible equipment. Its dimensions, frame style, and connection layout make it suitable for installations where these specifications are required. Built to last, it provides dependable circuit protection while helping you keep existing electrical systems in service.

Key Features and Benefits

• 80 Amp Current Rating: 80 Amp current rating.
• Two-Pole Design: Two-pole design.
• Type TEB Molded Case Circuit Breaker: Type TEB molded case circuit breaker.
• E150 Frame: E150 frame.
• Non-Interchangeable Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit.
• 10k A.I.C. Rating: 10k A.I.C. rating at 120/240VAC.
• Cable-In/Cable-Out Construction: Cable-in/cable-out (lug-lug) construction.
• Line and Load-Side Lugs Included: Includes both line-side and load-side lugs.
• Form, Fit, and Functional Replacement: Designed for form, fit, and functional replacement in compatible systems.


Technical Specifications

• Part Number: TEB122080WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 80 Amps

• Voltage: 120/240VAC

• Interrupting Rating: 10k A.I.C.

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-in/Cable-out (Lug-Lug)

• Included: Line and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Circuit Breaker Construction: Molded case circuit breaker construction.
• Thermal Magnetic Overcurrent Protection: Thermal magnetic overcurrent protection.
• Rated 10k A.I.C. at 120/240VAC: Rated 10k A.I.C. at 120/240VAC.
• Installation: Install only in equipment verified to be compatible and in accordance with applicable electrical codes.


Where It Works Best

• The TEB122080WL is commonly installed in commercial buildings, industrial facilities, manufacturing equipment, and distribution panels that require a 2-pole, 80-amp Type TEB circuit breaker. It is intended for maintaining compatible legacy equipment where the original frame size, electrical ratings, and lug configuration need to be matched.
