GENERAL ELECTRIC
TEB122080 **Older Style** - 80Amp Circuit Breaker
TEB122080 **Older Style** - 80Amp Circuit Breaker
Couldn't load pickup availability
TEB122080 **Older Style** - 80Amp Circuit Breaker
Finding the right replacement for your circuit breaker for an older electrical system means getting more than the amperage right. The frame, connection style, voltage rating, and physical dimensions all matter. The TEB122080 Older Style Black Face Circuit Breaker is an 80-amp, 2-pole molded-case industrial circuit breaker with a TEB series E150 frame, bolt-on mounting, and a non-interchangeable thermal-magnetic trip unit. Designed for compatible legacy electrical equipment, this breaker provides a practical solution when the original installation requires these specific electrical and mechanical characteristics.
Key Features and Benefits
- 80 Amp Current Rating: Designed for compatible electrical circuits requiring an 80-amp molded-case circuit breaker.
- 2 Pole Design: Provides two-pole circuit protection in equipment designed for this configuration.
- Older Style Black Face: Helps identify the breaker style when matching components in existing electrical installations.
- Bolt-On Configuration: Designed for equipment requiring this particular line-side connection and mounting arrangement.
- Load-Side Lugs Included: Provides the designated connection points for the outgoing conductor. Line-side lugs are not specified as included.
- 120/240VAC Rating: Intended for applications operating within the stated voltage rating.
- Thermal Magnetic Protection: Combines thermal overload response with magnetic short-circuit response.
Technical Specifications
-
Part Number: TEB122080
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage: 80 Amps
-
Number of Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
-
Mounting / Connection Configuration: Bolt-On
-
Load-Side Lugs: Included
-
Line-Side Connection: Bolt-On Configuration
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit Type: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122080 molded case circuit breaker features a molded enclosure and a non-interchangeable thermal magnetic trip mechanism. This construction provides the specified overload and short-circuit protection functions within a single breaker assembly.
The available product specifications do not independently verify the exact molded housing material composition, UL listing, CSA certification, or RoHS compliance. Where a particular certification or material requirement applies, confirm the markings on the actual breaker and consult the relevant manufacturer documentation.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Equipment
- Industrial Electrical Systems
- Commercial Electrical Installations
- Facility Maintenance and Repair
- Bolt-On Circuit Breaker Applications
- Electrical Equipment Servicing
