TEB122080 - 80Amp Circuit Breaker

TEB122080 - 80Amp Circuit Breaker

The TEB122080 is a 2-pole, 80-amp molded case circuit breaker designed for use in your compatible commercial and industrial electrical distribution systems. Built on the E150 frame, this Type TEB bolt-on breaker features a non-interchangeable thermal magnetic trip unit that responds to overloads and short circuits to help you protect connected equipment and wiring. Rated for 120/240VAC with a 10kA interrupting capacity, it is intended for applications where matching the original equipment specifications is important. Load-side lugs are included, making installation more straightforward. Built to last, the TEB122080 provides a dependable form, fit, and functional replacement for compatible legacy electrical systems.

Key Features and Benefits

• Part Number: TEB122080
• 80 Amp Current Rating: 80 Amp current rating
• Two-Pole Configuration: Two-pole configuration
• Type TEB Circuit Breaker: Type TEB molded case circuit breaker
• Bolt-On Mounting: Bolt-on mounting
• E150 Frame: E150 frame
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit
• 10kA Interrupting Rating: 10kA interrupting rating at 120/240VAC
• Load-Side Lugs Included: Includes load-side lugs
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible equipment
• Built to Last: Built to last in commercial and industrial applications


Technical Specifications

• Part Number: TEB122080

• Type: TEB

• Frame: E150

• Circuit Breaker Style: Molded Case Industrial Circuit Breaker

• Mounting: Bolt-On

• Poles: 2

• Amperage: 80A

• Voltage: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Lugs: Load-Side Lugs Included

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Original Specifications: Manufactured to the original electrical specifications for this breaker type.
• Thermal Magnetic Protection: Thermal magnetic trip unit provides overload and short-circuit protection.
• Compatible Equipment: Intended for installation in compatible equipment when used in accordance with applicable electrical codes.
• Installation Requirements: Always confirm compatibility with the existing panel or electrical distribution equipment before installation.


Where It Works Best

• The TEB122080 is commonly used in commercial buildings, industrial facilities, and other electrical distribution systems that require an 80-amp, 2-pole bolt-on circuit breaker. It is a suitable choice when replacing an existing Type TEB breaker in compatible panelboards or switchboards, helping maintain the original design and electrical ratings without changing the equipment configuration.
