TEB122070WL **Older Style** - 70Amp Circuit Breaker
TEB122070WL **Older Style** - 70Amp Circuit Breaker
Couldn't load pickup availability
TEB122070WL **Older Style** - 70Amp Circuit Breaker
When you're replacing a circuit breaker in an existing electrical system, the right part number is only the beginning. The mounting configuration, electrical ratings, frame size, and conductor connections must all match. The TEB122070WL Older Style Black Face Circuit Breaker is a 70 amp, 2-pole molded-case industrial circuit breaker from the TEB series, featuring an E150 frame, cable-in/cable-out (lug-lug) connections, and a non-interchangeable thermal-magnetic trip unit. It's a practical replacement option for compatible legacy electrical equipment that specifically requires this configuration.
Key Features and Benefits
- 70 Amp Current Rating: Designed for compatible circuits requiring a 70-amp molded-case circuit breaker.
- 2 Pole Configuration: Provides two-pole circuit protection for equipment requiring this electrical arrangement.
- Older-Style Black Face: A distinctive visual characteristic that helps identify this breaker style in legacy installations.
- Cable-In/Cable-Out (Lug-Lug) Connections: Features conductor termination points on both the incoming and outgoing sides.
- Line-Side and Load-Side Lugs Included: Both sets of lugs are supplied, which is essential when matching the original connection arrangement.
- 120/240VAC Voltage Rating: Suitable for applications requiring this voltage rating, subject to equipment compatibility.
- Thermal Magnetic Trip Mechanism: Combines thermal overload protection with magnetic short-circuit protection.
Technical Specifications
-
Part Number: TEB122070WL
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage: 70 Amps
-
Number of Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
-
Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
-
Line-Side Lugs: Included
-
Load-Side Lugs: Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit Type: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122070WL molded case circuit breaker features a molded enclosure and a non-interchangeable thermal magnetic trip mechanism. Its E150 frame, 70-amp rating, two-pole configuration, and cable-in/cable-out connections are key factors when evaluating its suitability for an existing electrical installation.
Where It Works Best
Common Applications:
- Legacy Electrical Distribution Equipment
- Industrial Electrical Systems
- Commercial Electrical Installations
- Facility Maintenance and Repair
- Cable-In/Cable-Out Breaker Applications
- Electrical Equipment Servicing
