TEB122070WL - 70Amp Circuit Breaker

TEB122070WL - 70Amp Circuit Breaker

The TEB122070WL is a 2-pole, 70-amp molded-case circuit breaker with a 10 kA interrupting rating at 120/240 VAC. It uses an E150 frame and is equipped with a non-interchangeable thermal magnetic trip unit for overload and short-circuit protection. This breaker has a cable-in/cable-out (lug-lug) configuration and includes both line-side and load-side lugs. It is intended for use in compatible equipment that requires a TEB-style breaker with matching electrical ratings and dimensions. When you're servicing existing power distribution equipment, matching the original breaker specifications helps maintain proper fit and operation. Like other molded case breakers of this design, the TEB122070WL is built for years of everyday service in commercial and industrial electrical systems.

Key Features and Benefits

• Part Number: TEB122070WL
• 70 Amp Current Rating: 70 Amp current rating
• Two-Pole Design: Two-pole design
• 10kA Interrupting Capacity: 10kA interrupting capacity at 120/240VAC
• E150 Frame: E150 frame
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit
• Cable-In/Cable-Out Construction: Cable-in/cable-out (lug-lug) construction
• Line-Side and Load-Side Lugs Included: Includes line-side and load-side lugs
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible TEB applications
• Built to Last: Built to last


Technical Specifications

• Part Number: TEB122070WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 70 Amps

• Voltage: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection Style: Cable-In/Cable-Out (Lug-Lug)

• Included: Line and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Circuit Breaker: Molded case circuit breaker
• Thermal Magnetic Trip Protection: Thermal magnetic trip protection
• Compatible Equipment: Designed for installation in compatible electrical equipment within its published ratings
• Installation Requirements: Install in accordance with applicable electrical codes and manufacturer instructions


Where It Works Best

• The TEB122070WL is commonly found in commercial and industrial power distribution equipment that accepts compatible TEB circuit breakers. It can be used in panelboards, switchboards, and similar electrical systems where a 70-amp, 2-pole, E150-frame breaker with a 120/240VAC, 10kA rating is required.
