GENERAL ELECTRIC
TEB122070 **Older Style** - 70Amp Circuit Breaker
TEB122070 **Older Style** - 70Amp Circuit Breaker
Couldn't load pickup availability
TEB122070 **Older Style** - 70Amp Circuit Breaker
Finding the right circuit breaker for an older electrical system starts with matching the key details. The TEB122070 Older Style Black Face Circuit Breaker is a 70-amp, 2-pole molded-case industrial circuit breaker featuring a TEB series E150 frame, bolt-on mounting, and a non-interchangeable thermal-magnetic trip unit. Designed for your compatible electrical equipment, this breaker provides a form, fit, and function replacement for installations that require its electrical ratings and physical configuration.
Key Features and Benefits
- 70 Amp Current Rating: Designed for compatible electrical circuits that require a 70-amp molded-case circuit breaker.
- 2 Pole Configuration: Provides a two-pole switching and protection arrangement for applications requiring this breaker type.
- Older Style Black Face: Features the distinctive face style used to identify this breaker configuration in existing equipment.
- TEB Series, E150 Frame: Matches the specified series and frame characteristics required for compatible replacement applications.
Technical Specifications
-
Part Number: TEB122070
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage Rating: 70 Amps
-
Number of Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Capacity (AIC): 10,000 Amps (10k AIC) at 120/240VAC
-
Mounting / Connection Type: Bolt-On
-
Load-Side Lugs: Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122070 circuit breaker features molded-case construction and a non-interchangeable thermal-magnetic trip mechanism. Its E150 frame and bolt-on configuration are important characteristics when evaluating suitability for existing electrical equipment.
Where It Works Best
- Legacy Electrical Distribution Systems
- Industrial Electrical Equipment
- Commercial Electrical Installations
- Facility Maintenance and Repairs
- Bolt-On Breaker Replacement
- Electrical Equipment Servicing
