TEB122070 - 70Amp Circuit Breaker

TEB122070 - 70Amp Circuit Breaker

The TEB122070 is a 2-pole, 70-amp Type TEB molded case circuit breaker designed for use in you compatible electrical distribution equipment requiring a bolt-on mounting configuration. Built on the E150 frame, this breaker features a non-interchangeable thermal magnetic trip unit that provides dependable protection against overloads and short circuits in 120/240VAC systems. Load-side lugs are included to simplify installation in compatible panelboards and switchboards. Designed for lasting service, the TEB122070 is a form, fit, and functional replacement for compatible legacy electrical systems, making it a practical choice for maintenance, repair, and equipment servicing where matching specifications are essential.

Key Features and Benefits

• 70 Amp Current Rating: 70 Amp current rating for branch circuit protection.
• 2-Pole Configuration: 2-pole configuration for 120/240VAC applications.
• Bolt-On Mounting: Bolt-on mounting for secure installation in compatible equipment.
• E150 Frame Construction: E150 frame construction.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit for overload and short-circuit protection.
• 10kA Interrupting Capacity: 10kA interrupting capacity at 120/240VAC.
• Load-Side Lugs Included: Includes load-side lugs for convenient field installation.
• Molded Case Design: Molded case design built for long-term durability.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible Type TEB applications.


Technical Specifications

• Part Number: TEB122070

• Type: TEB

• Frame: E150

• Circuit Breaker Type: Molded Case Industrial Circuit Breaker

• Mounting: Bolt-On

• Poles: 2

• Amperage: 70 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating (A.I.C.): 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Line/Load Connection: Includes Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Construction: Molded case circuit breaker construction for industrial electrical distribution applications.
• Thermal Magnetic Trip Mechanism: Thermal magnetic trip mechanism provides combined overload and instantaneous short-circuit protection.
• Electrical System Compatibility: Manufactured for use in compatible electrical systems when installed according to applicable electrical codes and equipment specifications.
• Installation Requirements: Always verify equipment compatibility, interrupting capacity, voltage rating, and local code requirements before installation.


Where It Works Best

• The TEB122070 is well suited for commercial, industrial, and institutional electrical systems that require a 70-amp, 2-pole bolt-on circuit breaker. It is commonly used in compatible panelboards, switchboards, distribution equipment, and other power distribution applications where maintaining the original equipment configuration is important. When replacing an existing Type TEB breaker, matching the frame, mounting style, ampere rating, pole count, and interrupting rating helps ensure proper fit and intended operation within compatible legacy systems.
