GENERAL ELECTRIC

TEB122060WL **Older Style** - 60Amp Circuit Breaker

TEB122060WL **Older Style** - 60Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122060WL **Older Style** - 60Amp Circuit Breaker

When you're replacing a circuit breaker in an older electrical system, getting the details right matters. The TEB122060WL Older Style Black Face Circuit Breaker is a 60-amp, 2-pole molded-case industrial circuit breaker designed for compatible electrical distribution equipment. As part of the TEB series, it features an E150 frame, cable-in/cable-out (lug-lug) connections, and a non-interchangeable thermal-magnetic trip unit. For maintenance professionals and electricians working with existing equipment, these specifications help identify the correct breaker configuration without unnecessary installation changes.

Key Features and Benefits

  • 60 Amp, 2 Pole Configuration: Designed for compatible electrical circuits requiring a 60-amp, two-pole molded-case circuit breaker.
  • Older-Style Black Face: Provides a recognizable visual characteristic for identifying breakers in existing electrical equipment.
  • E150 Frame: Features the frame configuration required by electrical equipment designed to accommodate this breaker.
  • Cable-In/Cable-Out (Lug-Lug) Connections: Uses a lug-lug terminal arrangement for applications requiring cable connections on both sides of the breaker.
  • Line and Load-Side Lugs Included: Supplied with lugs on both the incoming and outgoing conductor sides.

Technical Specifications

  • Part Number: TEB122060WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame Type: E150
  • Face Style: Older Style Black Face
  • Amperage Rating: 60 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity (AIC): 10,000 Amps (10k AIC) at 120/240VAC
  • Connection Type: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122060WL circuit breaker features molded-case construction with an integrated thermal-magnetic trip mechanism. Its E150 frame and cable-in/cable-out connection arrangement are intended for compatible electrical equipment requiring these specific characteristics.

Where It Works Best

Common Applications:

  • Legacy Electrical Systems
  • Industrial Electrical Distribution
  • Commercial Electrical Equipment
  • Facility Maintenance and Repairs
  • Cable-In/Cable-Out Breaker Applications
  • Electrical Equipment Servicing
