TEB122060WL - 60Amp Circuit Breaker

TEB122060WL - 60Amp Circuit Breaker

The TEB122060WL is a 2-pole, 60-amp molded case industrial circuit breaker designed for dependable circuit protection in your commercial and industrial electrical distribution systems. Built on the E150 frame, this TEB series breaker features a non-interchangeable thermal magnetic trip unit that provides protection against both overloads and short circuits. Its cable-in/cable-out (lug-lug) configuration, complete with factory-installed line- and load-side lugs, helps you simplify installation in compatible equipment. Rated 10kA at 120/240VAC, the TEB122060WL is well suited as a form, fit, and functional replacement in existing systems where matching electrical ratings and physical compatibility are essential. Designed for long service life, it delivers the dependable protection expected in demanding electrical applications while helping you to maintain the integrity of legacy power distribution equipment.

Key Features and Benefits

• 60-Amp Molded Case Circuit Breaker: 60-amp molded case industrial circuit breaker
• 2-Pole Design: 2-pole design for 120/240VAC electrical systems
• 10kA Interrupting Capacity: 10kA interrupting capacity at 120/240VAC
• TEB Series, E150 Frame: TEB series with E150 frame
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit for overload and short-circuit protection
• Cable-In/Cable-Out Configuration: Cable-in/Cable-out (Lug-Lug) configuration
• Line- and Load-Side Lugs Included: Includes line-side and load-side lugs for installation
• Form, Fit, and Functional Replacement: Designed as a form, fit, and functional replacement for compatible TEB series applications
• Built to Last: Built to last for continued use in commercial and industrial electrical systems


Technical Specifications

• Part Number: TEB122060WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 60A

• Voltage Rating: 120/240VAC

• Interrupting Rating (A.I.C.): 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Configuration: Cable-In/Cable-Out (Lug-Lug)

• Line/Load Lugs: Included

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Product Standards: The TEB122060WL is manufactured for use in commercial and industrial electrical systems and is designed to meet the applicable product standards for its original application.
• Installation Requirements: Always verify compatibility with your equipment, electrical ratings, and local code requirements before installation. Installation and servicing should be performed by qualified electrical personnel in accordance with applicable electrical codes and manufacturer recommendations.


Where It Works Best

• The TEB122060WL is well suited for use in compatible panelboards, switchboards, industrial control equipment, and commercial power distribution systems that require a 2-pole, 60A, 120/240VAC molded case circuit breaker with a 10kA interrupting rating. It is an excellent choice when maintaining or servicing existing electrical infrastructure where matching the original form, fit, and function is critical for continued operation.
