GENERAL ELECTRIC

TEB122060 **Older Style** - 60Amp Circuit Breaker

TEB122060 **Older Style** - 60Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122060 **Older Style** - 60Amp Circuit Breaker

When it's time to replace a circuit breaker in an existing electrical system, the details matter. You need more than the correct amperage. The frame, connection style, voltage rating, and physical dimensions must also match the equipment's requirements. The TEB122060 Older Style Black Face Circuit Breaker is a 60-amp, 2-pole2-pole molded-case industrial circuit breaker designed for compatible electrical installations that require a TEB series breaker with an E150 frame and bolt-on connection configuration.

Key Features and Benefits

  • 60 Amp Current Rating: Designed for compatible electrical circuits requiring a 60-amp molded-case circuit breaker.
  • 2 Pole Configuration: Provides two-pole circuit protection for electrical equipment designed for this breaker arrangement.
  • Older Style Black Face: Features the recognizable face design associated with this TEB breaker configuration, helping with identification during maintenance and replacement.
  • 120/240VAC Voltage Rating: Intended for compatible electrical systems operating within the breaker's specified voltage rating.
  • Bolt-On Connection Style: Features a bolt-on arrangement for installations specifically designed to accept this configuration.
  • Load-Side Lugs Included: Provides the specified load-side conductor connections. Line-side lugs are not identified as included.
  • Thermal Magnetic Protection: Uses thermal and magnetic trip functions to respond to overload and short-circuit conditions.

Technical Specifications

  • Part Number: TEB122060
  • Product Type: Molded Case Industrial Circuit Breaker
  • Type / Series: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 60 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Connection Configuration: Bolt-On
  • Load-Side Connections: Lugs Included
  • Line-Side Connection: Bolt-On Configuration
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122060 circuit breaker features molded-case construction, an E150 frame, and a non-interchangeable thermal-magnetic trip unit.

Where It Works Best

Common applications include:

  • Legacy Electrical Systems
  • Industrial Electrical Distribution
  • Commercial Electrical Equipment
  • Facility Maintenance and Repairs
  • Bolt-On Breaker Applications
  • Electrical Equipment Servicing
