TEB122060 - 60Amp Circuit Breaker

TEB122060 - 60Amp Circuit Breaker

The TEB122060 is a 2-pole, 60-amp molded-case industrial circuit breaker designed for use in your 120/240 VAC electrical distribution systems. Built on the E150 frame, this bolt-on Type TEB circuit breaker features a non-interchangeable thermal magnetic trip unit that provides dependable protection against overloads and short circuits. Engineered for proper form, fit, and function in compatible panelboards and distribution equipment, it includes load-side lugs to simplify installation. Built to last, the TEB122060 is well-suited for maintaining and servicing existing electrical systems where matching electrical ratings, mounting configuration, and breaker type are essential. Its combination of a 60-amp rating, 10 kA interrupting capacity, and bolt-on design makes it a practical solution for a wide range of commercial and industrial branch-circuit applications.

Key Features and Benefits

• 60 Amp Current Rating: 60 Amp current rating for branch circuit protection.
• 2-Pole Configuration: 2-pole configuration for 120/240VAC applications.
• 10kA A.I.C. Rating: 10kA A.I.C. rating at 120/240VAC.
• Type TEB Circuit Breaker: Type TEB molded case industrial circuit breaker.
• E150 Frame Construction: E150 frame construction.
• Bolt-On Mounting: Bolt-on mounting for secure installation in compatible equipment.
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit provides overload and short-circuit protection.
• Load-Side Lugs Included: Includes load-side lugs for added installation convenience.
• Legacy System Compatibility: Designed for compatibility with applicable legacy electrical distribution systems.
• Built to Last: Built to last for dependable service in demanding environments.


Technical Specifications

• Part Number: TEB122060

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 60 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating (A.I.C.): 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Mounting: Bolt-On

• Included Accessories: Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Construction: Molded case industrial circuit breaker construction.
• Thermal Magnetic Trip Technology: Thermal magnetic trip technology for overload and short-circuit protection.
• Electrical Distribution Equipment: Manufactured for use in compatible electrical distribution equipment in accordance with the product's published electrical ratings.
• Installation Requirements: Verify compatibility with the intended panelboard or electrical system before installation.


Where It Works Best

• The TEB122060 is ideal for commercial, industrial, and institutional electrical distribution systems requiring a 2-pole, 60-amp bolt-on circuit breaker. It is commonly used in panelboards, switchboards, and distribution equipment where a Type TEB, E150 frame breaker with a 10 kA interrupting rating at 120/240 VAC is specified. This breaker is intended as a form, fit, and functional replacement in compatible existing installations, helping maintain the original electrical design and protection requirements while supporting dependable operation.
