GENERAL ELECTRIC

TEB122050WL **Older Style** - 50Amp Circuit Breaker

TEB122050WL **Older Style** - 50Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122050WL **Older Style** - 50Amp Circuit Breaker

Replacing your circuit breaker in an older electrical system isn't just about matching the amperage. The mounting arrangement, terminal connections, frame size, and electrical ratings must match the original equipment. The TEB122050WL Older Style Black Face Circuit Breaker is a 50-amp, 2-pole2-pole molded-case industrial circuit breaker designed for compatible installations that require a TEB series breaker with an E150 frame and cable-in/cable-out (lug-lug) connections. Unlike a bolt-on configuration, this model includes both line-side and load-side lugs, so its terminal arrangement is a key factor when identifying the correct replacement.

Key Features and Benefits

  • 50 Amp, 2 Pole Configuration: Designed for compatible electrical circuits requiring a 50 amp, two-pole breaker.
  • Older Style Black Face: Helps identify the breaker style used in certain established electrical installations.
  • 120/240VAC Voltage Rating: Rated for use in compatible systems operating within the specified voltage requirements.
  • E150 Frame: Features the frame configuration specified for equipment designed to accommodate this breaker type.
  • Cable-In/Cable-Out (Lug-Lug) Connections: Uses conductor lug connections on both the line and load sides.
  • Line and Load-Side Lugs Included: Provides the specified terminals for connecting incoming and outgoing conductors.

Technical Specifications

  • Part Number: TEB122050WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Type / Series: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 50 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Mounting / Connection Style: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Terminals: Lugs Included
  • Load-Side Terminals: Lugs Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122050WL molded case circuit breaker features an enclosed molded case design, an E150 frame, and a non-interchangeable thermal magnetic trip unit. Its cable-in/cable-out configuration includes line-side and load-side lugs, providing a terminal arrangement compatible with electrical installations.

Where It Works Best

Common applications include:

  • Legacy Electrical Systems
  • Industrial Electrical Distribution
  • Commercial Electrical Equipment
  • Facility Maintenance and Repairs
  • Cable-In/Cable-Out Applications
