GENERAL ELECTRIC
TEB122050 **Older Style** - 50Amp Circuit Breaker
TEB122050 **Older Style** - 50Amp Circuit Breaker
Couldn't load pickup availability
TEB122050 **Older Style** - 50Amp Circuit Breaker
When you're replacing a circuit breaker in an established electrical system, the details matter. The right replacement needs to match more than the amperage printed on the handle. Frame size, mounting style, electrical ratings, and terminal connections all matter. The TEB122050 Older Style Black Face Circuit Breaker is a 50-amp, 2-pole2-pole molded-case industrial circuit breaker designed for compatible electrical equipment requiring the TEB series, E150 frame, and bolt-on mounting configuration. With a 120/240VAC voltage rating and 10 kA interrupting capacity, it provides thermal-magnetic protection against overloads and short circuits within its specified ratings.
Key Features and Benefits
- 50 Amp, 2 Pole Design: Rated for applications requiring a 50 amp, two-pole circuit breaker.
- Older Style Black Face: Provides an identifiable appearance when matching breakers in existing electrical equipment.
- 120/240VAC Voltage Rating: Designed for compatible electrical systems operating within the specified voltage rating.
- E150 Frame Configuration: Features a defined frame size for installations designed to accommodate this breaker type.
- Bolt-On Mounting: Designed for compatible equipment requiring a bolt-on breaker connection.
- Load-Side Lugs Included: Provides the specified load-side conductor connection arrangement.
- Thermal Magnetic Protection: Uses thermal and magnetic trip functions to respond to overload and short-circuit conditions.
Technical Specifications
-
Part Number: TEB122050
-
Product Type: Molded Case Industrial Circuit Breaker
-
Series / Type: TEB
-
Frame: E150
-
Face Style: Older Style Black Face
-
Amperage: 50 Amps
-
Poles: 2
-
Voltage Rating: 120/240VAC
-
Interrupting Rating: 10k AIC at 120/240VAC
-
Mounting Configuration: Bolt-On
-
Terminal Configuration: Load-Side Lugs Included
-
Trip Mechanism: Thermal Magnetic
-
Trip Unit: Non-Interchangeable
-
Width: 2.75 inches
-
Height / Length: 6.31 inches
-
Depth: 3.38 inches
-
Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
-
Shipping Weight: 4.00 lbs.
Material Compliance and Certifications
The TEB122050 molded case circuit breaker features an enclosed molded case design and a non-interchangeable thermal magnetic trip unit. Its construction houses the breaker's switching and protective components, while its bolt-on mounting arrangement and included load-side lugs provide the specified connection configuration.
Where It Works Best
Common applications include:
- Legacy Electrical Distribution Systems
- Industrial Electrical Equipment
- Commercial Electrical Installations
- Facility Maintenance and Repairs
- Existing Bolt-On Breaker Assemblies
