TEB122050 - 50Amp Circuit Breaker

TEB122050 - 50Amp Circuit Breaker

The TEB122050 is a 2-pole, 50-amp molded-case circuit breaker designed for use in your compatible commercial and industrial electrical distribution systems. It features an E150 frame, bolt-on mounting, and a non-interchangeable thermal magnetic trip unit that responds to both overloads and short circuits. Rated for 120/240VAC with a 10kA interrupting capacity, this breaker is intended for your applications where matching the original electrical ratings and mounting style is important. Load-side lugs are included, making installation straightforward in compatible equipment. Built to last, the TEB122050 is a dependable choice when maintaining existing electrical systems with the proper form, fit, and function.

Key Features and Benefits

• 50 Amp Current Rating: 50 amp current rating
• Two-Pole Configuration: Two-pole configuration
• Bolt-On Installation: Bolt-on installation
• E150 Frame Design: E150 frame design
• Thermal Magnetic Trip Unit: Non-interchangeable thermal magnetic trip unit
• Interrupting Rating: Rated 10kA at 120/240VAC
• Load-Side Lugs Included: Includes load-side lugs
• Molded Case Construction: Molded case construction is designed for long service life
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible applications


Technical Specifications

• Part Number: TEB122050

• Type: TEB

• Frame: E150

• Product Type: Molded Case Industrial Circuit Breaker

• Poles: 2

• Current Rating: 50 Amps

• Voltage Rating: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Mounting: Bolt-On

• Included: Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Manufacturing and Application: The TEB122050 is manufactured as a molded-case circuit breaker for use in electrical distribution equipment, matching its published ratings and configuration.
• Installation Requirements: Always verify compatibility with your panel or switchboard, and install the breaker in accordance with applicable electrical codes and the equipment manufacturer's requirements.


Where It Works Best

• This breaker is commonly used in commercial buildings, industrial facilities, control panels, and distribution equipment that require a 2-pole, 50-amp bolt-on circuit breaker with an E150 frame. It's well-suited for replacing an existing compatible breaker when matching the original specifications is essential for proper operation.
