GENERAL ELECTRIC

TEB122040WL **Older Style** - 40Amp Circuit Breaker

TEB122040WL **Older Style** - 40Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122040WL **Older Style** - 40Amp Circuit Breaker

Replacing your circuit breaker in an older electrical system? Finding the right amperage is only the beginning. The mounting configuration, terminal connections, frame size, and electrical ratings must match the equipment. The TEB122040WL Older Style Black Face Circuit Breaker is a 40-amp, 2-pole2-pole molded-case industrial circuit breaker designed for compatible electrical distribution systems that require this specific TEB configuration. With an E150 frame and cable-in/cable-out (lug-lug) connections, this breaker includes line-side and load-side lugs, making it suitable for installations with conductor connections at both ends.

Key Features and Benefits

  • 40 Amp, 2 Pole Configuration: Provides circuit protection for compatible electrical applications requiring a 40 amp, two-pole breaker.
  • Older Style Black Face: Helps identify the correct breaker style when matching components in existing electrical equipment.
  • E150 Frame: Features molded case construction with dimensions intended for equipment that accommodates this frame and breaker configuration.
  • Cable-In/Cable-Out (Lug-Lug) Connections: Designed for installations requiring lug terminals on both the incoming and outgoing conductor sides.
  • Line-Side and Load-Side Lugs Included: Provides the specified terminal arrangement for connecting conductors at both ends of the breaker.
  • Thermal Magnetic Trip Protection: Combines thermal overload protection with magnetic short-circuit protection.

Technical Specifications

  • Part Number: TEB122040WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Series / Type: TEB
  • Frame Type: E150
  • Face Style: Older Style Black Face
  • Amperage Rating: 40 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity (AIC): 10,000 Amps (10k AIC) at 120/240VAC
  • Connection Type: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Lugs: Included
  • Load-Side Lugs: Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122040WL circuit breaker features molded-case construction with a non-interchangeable thermal-magnetic trip unit. Its E150 frame and cable-in/cable-out connection arrangement are intended for electrical equipment that requires these specific characteristics.

Where It Works Best

Common applications include:

  • Legacy Electrical Distribution Systems
  • Industrial Electrical Equipment
  • Commercial Electrical Installations
  • Facility Maintenance and Repairs
  • Existing Lug-Lug Connection Assemblies
