TEB122030WL - 30Amp Circuit Breaker

TEB122030WL - 30Amp Circuit Breaker

The TEB122030WL is a 2-pole, 20-amp molded case circuit breaker with an E150 frame and a non-interchangeable thermal magnetic trip unit. It is rated for 120/240VAC systems with a 10kA interrupting capacity. This breaker uses a cable-in/cable-out (lug-lug) connection and includes both line-side and load-side lugs. If you're replacing an existing TEB breaker, matching the frame, amp rating, voltage, and connection style is important. The TEB122030WL is built for that purpose, making it a practical form, fit, and functional replacement in compatible equipment. Its thermal magnetic trip unit responds to overloads and short circuits while the molded case construction is built to last in everyday commercial and industrial service.

Key Features and Benefits

• 20 Amp Rating: 20 Amp rating.
• 2 Poles: 2 poles.
• E150 Frame: E150 frame.
• Thermal Magnetic Trip Unit: Thermal magnetic, non-interchangeable trip unit.
• Rated 120/240VAC: Rated 120/240VAC.
• 10kA Interrupting Capacity: 10kA interrupting capacity.
• Cable-In/Cable-Out Design: Cable-in/cable-out (lug-lug) design.
• Line- and Load-Side Lugs Included: Includes line- and load-side lugs.
• Form, Fit, and Functional Replacement: Form, fit, and functional replacement for compatible TEB applications.
• Built to Last: Built to last.


Technical Specifications

• Part Number: TEB122030WL

• Type: TEB

• Frame: E150

• Poles: 2

• Amperage: 20A

• Voltage: 120/240VAC

• Interrupting Rating: 10kA @ 120/240VAC

• Trip Unit: Non-Interchangeable Thermal Magnetic

• Connection: Cable-in/Cable-out (Lug-Lug)

• Included: Line- and Load-Side Lugs

• Dimensions:
  • Height: 6.31 in.
  • Width: 2.75 in.
  • Depth: 3.38 in.

Material Compliance and Certifications

• Molded Case Industrial Circuit Breaker: Molded case industrial circuit breaker.
• Thermal Magnetic Protection: Thermal magnetic protection for overload and short-circuit conditions.
• Compatible Equipment: Manufactured for use in compatible electrical distribution equipment.
• Installation Requirements: Confirm compatibility with your equipment before installation and follow applicable electrical codes.


Where It Works Best

• This breaker is commonly found in commercial buildings, industrial facilities, and other power distribution systems using TEB breakers. It is intended for applications where the original breaker's frame size, electrical ratings, and lug-lug connection need to be maintained.
