GENERAL ELECTRIC

TEB122020WL **Older Style** - 20Amp Circuit Breaker

TEB122020WL **Older Style** - 20Amp Circuit Breaker

Regular price $340.00 USD
Regular price Sale price $340.00 USD
Sale Sold out
Shipping calculated at checkout.
Condition

TEB122020WL **Older Style** - 20Amp Circuit Breaker

When you're maintaining an older electrical system, finding the right circuit breaker means matching more than just the amperage. The TEB122020WL Older Style Black Face Circuit Breaker is a 20-amp, 2-pole molded-case industrial circuit breaker for compatible electrical equipment that requires a TEB-type, E150-frame breaker with cable-in/cable-out (lug-lug) connections. With a 120/240VAC voltage rating and a 10k AIC interrupting rating at 120/240VAC, this breaker provides thermal-magnetic overload and short-circuit protection within its specified ratings.

Key Features and Benefits

  • 20 Amp, 2 Pole Configuration: Designed for compatible circuits requiring a 20-amp, two-pole molded-case circuit breaker.
  • Older-Style Black Face: Provides a recognizable physical characteristic to identify the required breaker style in existing electrical installations.
  • E150 Frame: Features the frame configuration specified for compatible electrical equipment.
  • Cable-In/Cable-Out (Lug-Lug) Design: Accommodates cable connections on both the line and load sides in equipment designed for this terminal arrangement.
  • Line and Load-Side Lugs Included: Provides the specified connection hardware on both sides of the breaker.

Technical Specifications

  • Part Number: TEB122020WL
  • Product Type: Molded Case Industrial Circuit Breaker
  • Type / Series: TEB
  • Frame: E150
  • Face Style: Older Style Black Face
  • Amperage: 20 Amps
  • Number of Poles: 2
  • Voltage Rating: 120/240VAC
  • Interrupting Capacity: 10k AIC (10,000 Amps) at 120/240VAC
  • Connection Configuration: Cable-In/Cable-Out (Lug-Lug)
  • Line-Side Connections: Lugs Included
  • Load-Side Connections: Lugs Included
  • Trip Mechanism: Thermal Magnetic
  • Trip Unit: Non-Interchangeable
  • Width: 2.75 inches
  • Height / Length: 6.31 inches
  • Depth: 3.38 inches
  • Overall Dimensions: 2.75"W x 6.31"L x 3.38"D
  • Shipping Weight: 4.00 lbs.

Material Compliance and Certifications

The TEB122020WL circuit breaker features molded-case construction, an E150 frame, and a non-interchangeable thermal-magnetic trip unit. Its cable-in/cable-out configuration includes line-side and load-side lugs, making the terminal arrangement an important consideration when evaluating compatibility with existing electrical equipment.

Where It Works Best

Common applications include:

  • Legacy Electrical Systems: Replacement work involving equipment that specifies the TEB122020WL or a manufacturer-approved equivalent.
  • Industrial Electrical Distribution: Compatible industrial assemblies requiring a 20 amp, two-pole molded case breaker with the stated voltage and interrupting ratings.
  • Commercial Electrical Equipment: Established commercial installations designed to accommodate the E150 frame and lug-lug connection arrangement.
  • Facility Maintenance and Repairs: Maintenance projects where the existing breaker's electrical and physical specifications must be preserved.
  • Cable-In/Cable-Out Applications: Equipment designed for cable connections at both the line and load terminals.
